32
- Active Digitizer/Touchscreen
Changing the Pen Battery
Figure 15. Replacing the Battery
• DO NOT REMOVE THE TIP OF THE PEN TO REPLACE THE BATTERY;
REMOVE ONLY THE CAP ON THE TOP OF THE PEN.
• THERE IS A RISK OF EXPLOSION IF THE BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES IN ACCORDANCE WITH
LOCAL INSTRUCTIONS.
The pen contains a AAAA-battery. Before proceeding, be sure
to have a new battery available.
1 Remove the rear Pen Cap (Figure 15).
2 Remove the battery from the pen barrel.
3 Insert the new battery into the pen barrel in the same
orientation as the one that was removed.
4 Close the rear Pen Cap.
