Accessories for your Tablet PC (opti
onal)
Connecting the Tablet PC to the cradle
It is possible to connect the Tablet PC to the cradle while it is running.
Disconnect the AC adapter from the Tablet PC before connecting the
Tablet PC to the docking cradle.
When the Tablet PC is connected to the cradle, you must connect
the AC adapter to the cradle.
Cradle
► Remove the AC plug of th e AC adapter from the power outlet.
► Remove the AC adapter cable from the DC jack (DC IN ) of the Tablet PC.
► Fold in the tablet stand so that it lies flat on the rear of the Tablet PC.
4
1
2
3
► Position the Tablet PC so that it lies against the storage surface of the cradle.
► Push the
Tablet PC on to the docking cradle in the direction of the arrow (1)
until yo
u feel it engage on the connector.
► Plug the AC adapter cable into the DC jack (DC IN) on the cradle (2).
► Connec
t t he AC cable to the AC adapter (3).
► Plug the AC cable into the power outlet (4).
46 Fujitsu
