Fujitsu STYLISTIC R727

To Next Page

To Previous Page

Accessories for your Tablet PC (opti

onal)

► Connect the AC adapter cable to th e DC input connector (DC IN) of the Tablet PC (3).

► Connect the pow

er cable to the AC adapter (4).

► Plug the power cable into the power outlet (5).

50 Fujitsu
