Trouble shooting 23 E42. 3
INDOOR UNIT Error Method:
Indoor unit Heat Ex. outlet temp.
Sensor Error
Indicate or Display:
Indoor Unit : Operation LED 4 times Flash, Timer LED 2 Times Flash,
Filter LED Continuous Flash.
Outdoor Unit : E.5 U.1
Error Code : 4 2
Detective Actuators:
Indoor Unit Controller PCB Circuit
Heat Exchanger Outlet Temp. Sensor
Detective details:
When open or shorted Heat Exchanger outlet temp. sensor is detected
Forecast of Cause :
1. Connector defective connection 2.Sensor defective 3.Controller PCB defective
Check Point 1 : Check connection of Connector
Check if connector is loose or removed
Check erroneous connection
Check if Sensor cable is open
>>Reset Power when reinstalling due to removed connector or incorrect wiring.
OK
Check Point 3 : Check voltage of Controller PCB (DC5.0V)
Corresponding connector
Heat Ex Outlet temp. Sensor
(Gray Wires)
DC
Sensor Characteristics (Rough value)
If Thermistor is either open or shorted, replace it and reset the power.
OK
Check Point 2 : Remove connector and check sensor resistance value
32.4
35
40.0
30
49.862.579.1100.9129.8168.6
3.032.772.502.221.931.651.391.14
2520151050
Temperature (°C)
17.821.626.3
3.693.493.27
504540
Temperature (°C)
Voltage Value (V)
Resistance Value (k )
Voltage Value (V)
Resistance Value (k )
04-31
Model Type
If the voltage does not appear, replace Controller PCB and set up the original address.
Cassette type
Duct type
Compact Wall mounted type
Wall mounted type
Floor / Ceiling type
Compact Floor type
CN5 or CN9
CN9
CN5 or CN21
CN5 or CN9
CN9
CN5
To Next Page
