Setting number Default Details
Filter
indicator
interval
11
00 Standard
Adjust the filter cleaning interval notification. If the notification is too
early, change to setting 01. If the notification is too late, change to
setting 02.
01 Longer
02 Shorter
Filter
indicator
action
13
00 Enable
Enable or disable the filter indicator.
Setting 02 is for use with a central remote control.
01 Disable
02
Display only on
central remote
control
Ceiling
airflow
20
00 Standard
Regulate the airfl ow according to the needs of the installation location.
When set to 01, the air flow will be stronger. (Cassette type only)
01 High Ceiling
Vertical
airflow
direction
23
00 Standard
Adjust the vertical airflow direction. All airflow direction louvers are
adjusted together.
(Cassette type only)
01 Raise
Horizontal
swing
airflow
direction
24
00 Standard
Adjust the horizontal swing airflow direction.
(For horizontal swing equipped models)
01 Left half
02 Right half
Static pressure 26
00 SP mode 00
01
02
Indoor unit address 00
Ref. circuit address 00
00~63
00~99
Model name
Range of static
pressure
Normal static
pressure
ARXK07GCLH
SP mode 00 to 03 10 PaARXK09GCLH
ARXK12GCLH
ARXK14GCLH
SP mode 00 to 05 15 PaARXK18GCLH
ARXK24GCLH
ARXD04GALH
SP mode 00 to 09
(0 to 90 Pa)
25Pa
ARXD07GALH
ARXD09GALH
ARXD12GALH
ARXD14GALH
ARXD18GALH
ARXD24GALH
SP mode 00 to 05
(0 to 50 Pa)
ARXA24GBLH
SP mode 00 to 14
40Pa
ARXA30GBLH
50Pa
ARXA36GBLH SP mode 00 to 12
ARXA45GBLH SP mode 00 to 11 60Pa
ARXC36GBTH SP mode 02 to 16 100Pa
ARXC72GBTH SP mode 04 to 27
150PaARXC90GBTH SP mode 05 to 24
ARXC96GATH SP mode 05 to 29
ARXN18GATH SP mode 05 to 10
50Pa
ARXN24GATH SP mode 05 to 15
ARXN30GATH
SP mode 05 to 25
ARXN34GATH
ARXN36GATH
60Pa
ARXN45GATH
Please refer to "Chapter04 7.FAN PERFORMANCE CURVE" for the
characteristics of each indoor unit.
01 SP mode 01
02 SP mode 02
03 SP mode 03
04 SP mode 04
05 SP mode 05
06 SP mode 06
07 SP mode 07
08 SP mode 08
09 SP mode 09
10 SP mode 10
11 SP mode 11
12 SP mode 12
13 SP mode 13
14 SP mode 14
15 SP mode 15
16 SP mode 16
17 SP mode 17
18 SP mode 18
19 S
P mode 19
20 SP mode 20
21 SP mode 21
22 SP mode 22
23 SP mode 23
24 SP mode 24
25 SP mode 25
26 SP mode 26
27 SP mode 27
28 SP mode 28
29 SP mode 29
31 Normal SP
Cool air tem-
perature trigger
30
00 Standard
Adjust the cool air trigger temperature. To lower the trigger
temperature, use setting 01. To raise the trigger temperature,
use setting 02.
01 Adjust (1)
02 Adjust (2)
Heat air tem-
perature trigger
31
00 Standard
Adjust the heat air trigger temperature. To lower the trigger
temperature by 6 degrees C, use setting 01. To lower the trigger
temperature by 4 degrees C, use setting 02. To raise the trigger
temperature, use setting 03.
01 Adjust (1)
02 Adjust (2)
03 Adjust (3)
FUNCTION FUNCTION SETTING
1-5 FIELD SETTING / FUNCTION SETTING FOR INDOOR UNIT
Address
01-19
