SERVICE PARTS INFORMATION 4
Inverter PCB
Filter
Power PCB
PCB
Check Diode Bridge
Replace Reactor
Electric parts check
Replace Diode Bridge
NG
NG
(1) Check Circuit of Diode Bridge (After removing)
Refer to the Service parts information 11
Check Wire unplugged and lose screw Filter PCB -> DB -> Reactor -> Power PCB -> Inverter PCB
(2) Check the wire connection Filter PCB -> DB -> Reactor -> Power PCB -> Inverter PCB
If there is unplugged wire, connect the wire.
Replace Inverter PCB
YES
NO
Check Inverter PCB -4
(4) Disconnect the connection wires (7-pin connector)
between the Inverter PCB - Main PCB.
(5) Is there a short between Inverter PCB side connector pins 1-2 ?
Inverter PCB side short circuit
Replace Inverter PCB
Filter PCB side short circuit
Replace Filter PCB
YES
Check Inverter PCB -5
(6) Disconnect the connection wires (3-pin connector)
between the Inverter PCB - Filter PCB.
(7) Is there a short between Inverter PCB side connector
pins 1-3 and Filter PCB side connector pins 1-3?
Turn on the power.
(8) Reconnect all the connection wires disconnected up to (1)-(7) to their original places.
(9) Turn on the AC power.
If the LED of the Inverter PCB does not light or blink, replaces the Inverter PCB-Filter PCB.
NO
OK
NO
NO
Is the reactor Assy defective?
Check th e reactor (Refer to the parts information 6)
04-115
Replace Power PCB
YES
Check Resistance on the Power PCB
(3) Check the following items.
-1. The circuit between R801 and R804 is open-circuit
-2. The K801 is short-circuit
-3. R806 is open-circuit or short-circuit
OK
To Next Page
