14. RIGHT PANEL removal
06-11
Remove the mounting screws.
Remove the RIGHT PANEL by sliding upward.
Screws
Screws
13. PIPE COVER FRONT removal
Remove the mounting screws. Remove the PIPE COVER FRONT.
screw
(serrated)
screw
(with washer)
Hooks
