- (OU01 - 10) -
Outdoor unit / Single phase
OUTDOOR UNIT
WO
G112-140LCTA
OUTDOOR UNIT
WO
G112-140LCTA
DIMENSIONS3.
DIMENSIONAL DRAWING3-1.
MODELS : WO
G112LCTA, WO
G140LCTA
(Unit : mm)
900
1290
77 31
21
370
9
400
650
151
99
196
170
4-Ø12mm hole
12330
Air flow
Drain cap
mounting places
Top view
Side view
Bottom view
Front view
