FULTON Endura - Page 10

© Fulton Group N.A., Inc. 2022
INSTALLATION EDR-SOLA-IOM-2022-0216 SECTION 2
2-4
TABLE 1  BOILER DIMENSIONS AND OPERATING REQUIREMENTS
FIGURE 1  VIEWS OF ENDURA HYDRONIC BOILER
Alternate gas pressure arrangements may apply based on conguration and/
or local code requirements. Please verify gas pressure ratings for your boiler by
viewing the boiler name plate and consulting with the authority having jurisdiction.
Typical 120 VAC controls allow for a +10% and a -15% voltage uctuation.
Voltages lower than 120 V can result in slightly decreased available output.
*Standard congurations may be available as an option; please consult fac tor y.
Note: All dimensions are approximate and are subject to change without notice.
MODEL: EDR 750 1000 150 0 2000
Input
MM BTU/Hr
kW
.75
219
1.0
293
1.5
411
2.0
549
Fuel Cons. @ rated
cap. (Nat. Gas)
FT3/Hr
M3/Hr
750
21.2
1000
28.32
1500
42.5
2000
56.7
Output at AHRI Test
Condition
BHP
KCal/h
21.7
183,638
28.4
239,396
41.9
353,424
56
472,240
Natural Gas Pressure W.C. 4-28 4-28 4-28 4-28
Electrical*
120 V, 60 Hz, 1 Phase
20 Amp
(10FLA)
20 Amp
(10FLA)
25 Amp
(20FLA)
25 Amp
(20FLA)
Water Content
Gal
Liters
50
189
50
189
104
394
102
386
Dry Weight
LBS
KG
1430
649
1430
649
2260
1025
2260
1071
Operating Weight
LBS
KG
1848
838
1848
838
3128
1419
3210
1456
MODEL EDR 750 1000 1500 2000
A. Boiler Width
IN
CM
28
72
28
72
33.9
86
33.9
86
B. Overall Boiler Height
IN
CM
6 7.8
172.2
6 7.8
172.2
80
203.2
80
203.2
C. Overall Boiler Depth
IN
CM
50.2
127. 5
50.2
127. 5
60.6
153.8
60.6
153.8
D. Exhaust Outlet Diameter (ID)
IN
CM
6
15.2
6
15.2
6
15.2
8
15.2
E. Water Inlet/Outlet Diameter
IN
CM
2
5.08
2
5.08
4
10.2
4
10.2
F. Min. Clearance (top)
IN
CM
18
46
18
46
18
46
18
46
G. Air Inlet Diameter (top access)
IN
CM
6
15.25
6
15.25
8
20.3
8
20.3
H. Min. Clearance (sides)
IN
CM
1
2.5
1
2.5
1
2.5
1
2.5
FRONT VIEW RIGHT SIDE VIEW BACK VIEW
TOP VIEW
B
D
E
G
E
C
F
A
