FULTON Endura - Page 94

© Fulton Group N.A., Inc. 2022
MAINTENANCE EDR-SOLA-IOM-2022-0216 SECTION 4
4-10
FIGURE 77  EDR 750/1000 BURNER REGION ASSEMBLY
BILL OF MATERIAL
U.O.M.QTYDESCRIPTION
PART NUMBERITEM
EA.
1
3/4" NPT SIGHT OBSERVATION PORT
2-12-000012
1
EA.
2ENDURA 1000K BURNER GASKET, GRAFTECH GRAFOIL GTB2-12-0012702
EA.
1
3" WATER LEVEL PROBE
2-20-0000233
EA.
1
ENDURA DIRECT SPARK IGNITION ASSEMBLY2-20-000135
4
EA.
1
ENDURA IGNITER BRIDGE
2-20-000137
5
EA.
1
1/4" STAR WASHER
2-22-000048
6
EA.
6
3/8-16 NiCu400 HEX NUT (MONEL400)
2-22-000156
7
EA.
6
3/8" BELLEVILLE WASHER (INCONEL 718,.385" ID X 1.25" OD X .125" THK, .021" DISH)
2-22-000353
8
EA.
210-32 FLANGE STOP NUT - NYLON INSERT - STAINLESS
2-22-000388
9
EA.
2
10-32 X 25mm BOLT, 18.8 STAINLESS2-22-000389
10
EA.
1
1/2" X CL" - NPT SCH 40 NIPPLE
2-35-000085
11
EA.
1
3/4" X 1/2" 150# BUSHING
2-35-00026012
EA.
1
HONEYWELL MINI PEEPER2-40-00016113
EA.
1
THERMISTOR TEMP. SENSOR DUAL ELEMENT2-40-000332
14
EA.
1
TRANSFORMER 120V 50 / 60 Hz 15.6KVPK SECONDARY 28 MA
2-40-000976
15
EA.
1
ENDURA 750K / 1000K METAL MESH BURNER HEAD
2-40-071000
16
EA.
9FEMALE NYLON EXPANDED INSULATED SPLICE2-45-000093
17
EA.
1
FEMALE NYLON EXPANDED INSULATED CONNECTOR, 16-14 AWG2-45-000423
18
EA.
1
MOLEX CONNECTOR - 4 CIRCUITS - DUAL ROW MINI FIT2-45-00051419
F T.
1
16 AWG WIRE
2-45-00099920
EA.
1
HONEYWELL HEAT BLOCK ( 136733 )
2-45-00102721
EA.
1
18" LONG HIGH VOLTAGE IGNITION CABLE WITH 1/4" FEMALE CONNECTIONS
5-11-00001822
7
8
17
13
21
11
12
15
10
6
20
22
10
9
19
14
1
2
5
18
4
16
2
3
