FUNAI 27A-664 - Electrical Parts List

20030414 3-3-1 HE451EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
MCV CBA 0VSA14139
Consists of the following
MAIN CBA (MCV-A) ------------
SUB JACK CBA(MCV-B) ------------
JACK CBA (MCV-C) ------------
SENSOR CBA 0VSA13549
Ref. No. Description Part No.
Main CBA (MCV-A) -----------
Consists of the following
CAPACITORS
C002! METALLIZED FILM CAP. 0.068µF/275V K or CT2E683HJE06
! METALLIZED FILM CAP. 0.068µF/250V K CT2E683DC011
C003! SAFETY CAP. 2200pF/250V or CCN2EMP0E222
! SAFETY CAP. 2200pF/250V CA2E222MR049
C004 ELECTROLYTIC CAP. 33µF/400V M(L•Z) CA2H330NC010
C005 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103
C006 CERAMIC CAP. SL K 56pF/1KV or CCD3AKPSL560
CERAMIC CAP. SL J 56pF/1KV CCD3AJPSL560
C007 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C008 CERAMIC CAP.(AX) X K 5600pF/16V CCA1CKT0X562
C010 FILM CAP.(P) 0.022µF/50V J or CMA1JJS00223
FILM CAP.(P) 0.022µF/50V J CA1J223MS029
C011 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C012 ELECTROLYTIC CAP. 10µF/50V M H7 CE1JMAVSL100
C014 ELECTROLYTIC CAP. 470µF/35V M or CE1GMASDL471
ELECTROLYTIC CAP. 470µF/35V M CE1GMASTL471
C017 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTL471
C018 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C020 ELECTROLYTIC CAP. 1000µF/16V M CE1CMZPTL102
C021 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASDL471
ELECTROLYTIC CAP. 470µF/10V M CE1AMASTL471
C025 CERAMIC CAP.(AX) X K 5600pF/16V CCA1CKT0X562
C026 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C053 ELECTRIC DOUBLE LAYER CAP0.047F/5.5V Z
or
CA0J473NE003
ELECTRIC DOUBLE LAYER CAP. 0.047F/5.5V Z CA0J473MS014
C056 CHIP CERAMIC CAP. B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP. B K 0.047µF/25V CHD1EK30B473
C057 CHIP CERAMIC CAP. CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C060 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C061 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C157 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C158 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C251 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C252 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C253 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C254 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C302 CHIP CERAMIC CAP. B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP. B K 0.022µF/25V CHD1EK30B223
C303 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C304 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C305 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
C307 CHIP CERAMIC CAP. B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP. B K 0.047µF/25V CHD1EK30B473
C308 CHIP CERAMIC CAP. B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP. B K 0.022µF/25V CHD1EK30B223
C309 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C310 CHIP CERAMIC CAP. B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP. B K 0.047µF/25V CHD1EK30B473
C312 CHIP CERAMIC CAP. B K 8200pF/50V CHD1JK30B822
C313 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C314 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C315 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C316 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C317 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C318 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C319 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C320 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C321 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C322 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C323 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C324 CHIP CERAMIC CAP. CH J 68pF/50V or CHD1JJ3CH680
Ref. No. Description Part No.
