FUNAI 27A-664 - Page 65

20030414 3-3-3 HE451EL
C484 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C485 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C486 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C489 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C501 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C502 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C506 CERAMIC CAP.(AX) B K 100pF/50V CCA1JKT0B101
C508 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C510 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C511 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C512 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C513 CHIP CERAMIC CAP. CH J 22pF/50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C514 CHIP CERAMIC CAP. CH J 22pF/50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C515 CHIP CERAMIC CAP. CH J 18pF/50V or CHD1JJ3CH180
CHIP CERAMIC CAP. CG J 18pF/50V CHD1JJ3CG180
C516 CHIP CERAMIC CAP. CH J 18pF/50V or CHD1JJ3CH180
CHIP CERAMIC CAP. CG J 18pF/50V CHD1JJ3CG180
C517 CHIP CERAMIC CAP. B K 4700pF/50V CHD1JK30B472
C518 CHIP CERAMIC CAP. B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP. B K 0.047µF/25V CHD1EK30B473
C519 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C520 CHIP CERAMIC CAP. CH J 100pF/50V or CHD1JJ3CH101
CHIP CERAMIC CAP. CG J 100pF/50V CHD1JJ3CG101
C521 CHIP CERAMIC CAP. CH J 560pF/50V or CHD1JJ3CH561
CHIP CERAMIC CAP. CG J 560pF/50V CHD1JJ3CG561
C522 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C523 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C524 CHIP CERAMIC CAP. CH J 330pF/50V or CHD1JJ3CH331
CHIP CERAMIC CAP. CG J 330pF/50V CHD1JJ3CG331
C526 CHIP CERAMIC CAP. B K 4700pF/50V CHD1JK30B472
C527 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C529 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C530 CERAMIC CAP.(AX) F Z 0.022µF/25V CCA1EZTFZ223
C531 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C532 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C533 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C535 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C538 CHIP CERAMIC CAP. B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP. B K 0.022µF/25V CHD1EK30B223
C540 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C561 CHIP CERAMIC CAP. B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP. B K 0.022µF/25V CHD1EK30B223
C562 ELECTROLYTIC CAP. 330µF/6.3V M H7 CE0KMASSL331
C563 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C564 CHIP CERAMIC CAP. CH J 100pF/50V or CHD1JJ3CH101
CHIP CERAMIC CAP. CG J 100pF/50V CHD1JJ3CG101
Ref. No. Description Part No.
C640 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C642 SEMICONDUCTOR CAP. SR K 0.018µF/25V CDA1EKS0X183
C643 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C644 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C645 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C648 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C649 ELECTROLYTIC CAP. 1µF/50V M H7 NP CP1JMAVSB1R0
C701 CHIP CERAMIC CAP. B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP. B K 0.047µF/25V CHD1EK30B473
C702 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C703 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C704 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C706 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C707 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C708 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C716 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
C717 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
C756 CHIP CERAMIC CAP. CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C757 CHIP CERAMIC CAP. CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C851 CHIP CERAMIC CAP. CH J 22pF/50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C852 CHIP CERAMIC CAP. CH J 22pF/50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C853 CHIP CERAMIC CAP. B K 4700pF/50V CHD1JK30B472
C854 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C855 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C856 CHIP CERAMIC CAP. CH J 180pF/50V or CHD1JJ3CH181
CHIP CERAMIC CAP. CG J 180pF/50V CHD1JJ3CG181
C859 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C862 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
CONNECTOR
CN701 AFV PCB ASSEMBLY CP2500/C460 HC460AFV
DIODES
D001 RECTIFIER DIODE 1N4005 NDQZ001N4005
D002 RECTIFIER DIODE 1N4005 NDQZ001N4005
D003 RECTIFIER DIODE 1N4005 NDQZ001N4005
D004 RECTIFIER DIODE 1N4005 NDQZ001N4005
D005 RECTIFIER DIODE BA159 or NDQZ000BA159
RECTIFIER DIODE ERA22-10 QDPZ0ERA2210
D006 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D007 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D008 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D009 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D011 RECTIFIER DIODE BA158 NDQZ000BA158
D012 RECTIFIER DIODE FR202-B/P NDQZ000FR202
D013 RECTIFIER DIODE FR202-B/P NDQZ000FR202
Ref. No. Description Part No.
