1-7-7 HG242FIS
FUNCTION INDICATOR SYMBOLS
Note:
The following symbols will appear on the indicator panel to indicate the current mode or operation of the VCR.
On-screen modes will also be momentarily displayed on the tv screen when you press the operation buttons.
Display panel
[ 29B-250 ]
" H "= LED Light on, " L "= LED Light off
MODE INDICATOR ACTIVE
STANDBY Always " H " during electricity
FUNCTION Power on = " H "
Power off = " L "
TAPE IN Cassette in = " H "
Cassette out = " L "
TIMER Timer stand by = " H "
One touch recording = " H "
Timer recording = " H "
General mode = " L "
REC REC mode = " H "
REC pause
General mode = " L "
Blinks at 0.8Hz interval
When reel or capstan mechanism is not
functioning correctly
“A R” is displayed on a TV screen. (Refer to Fig. 1.)
When tape loading mechanism is not func-
tioning correctly
“A T” is displayed on a TV screen. (Refer to Fig. 2.)
When cassette loading mechanism is not
functioning correctly
“A C” is displayed on a TV screen. (Refer to Fig. 3.)
When the drum is not working properly
“A D” is displayed on a TV screen. (Refer to Fig. 4.)
P-ON Power safety detection
“A P” is displayed on a TV screen. (Refer to Fig. 5.)
TAPE IN TIMER RECFUNCTIONSTANDBY
