FUNAI 29B-250 - Mechanical Parts List

20040715 1-14-1 HG242CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a !
have special characteristics important to safety. Before
replacing any of these components, read carefully the
product safety notice in this service manual. Don't
degrade the safety of the product through improper ser-
vicing.
NOTE:
Parts that are not assigned part numbers (---------) are
not available.
Comparison Chart of Models and Marks
Model Mark
29B-250 A
29B-750 B
Ref. No. Mark Description Part No.
A1X A FRONT ASSEMBLY HE240ED 0VM203978
A1X B FRONT ASSEMBLY HE450ED 0VM204197
A2 CASE, TOP(ANTHRACITE) HE240ED 0VM101267
A3 A CHASSIS HE470ED 0VM000174A
A3 B CHASSIS(U27F-GMBH) HE240ED 0VM000177
A4 B JACK BOARD(U27 FTZ) HE480ED
(See Electrical Parts List)
A5 JACK BOARD(2-21P) HE470ED
(See Electrical Parts List)
A7 PANEL, BOTTOM HE470ED 0VM203862
A10! A LABEL, RATING HG242BD ----------
A10! B LABEL, RATING HG454BD ----------
A14 LABEL, SERIAL NO. HE240ED ----------
A14 A LABEL, BAR CODE HG242BD ----------
A14 B BARCODE LABEL HG454BD ----------
A21 B LABEL, CAUTION H2194BD ----------
A23 B INTERNAL WARNING LABEL(NEW)
H2194BD
----------
1B1 A DECK ASSEMBLY CZD013/VM23A0 N23A0FL
1B1 B DECK ASSEMBLY CZD013/VM23ED N23E0FL
2B5 SHEILD, CYLINDER HG470ED 0VM306638
2B7 SHIELD ASSEMBLY HG470ED
(See Electrical Parts List)
2B8 BUSH, LED(F) H3700UD
(See Electrical Parts List)
2B9 CUSHION HC460ED 0VM413251
2B18 FIBER, TOP CASE HC460ED 0VM412906
2B46 ROHM HOLDER H7770JD
(See Electrical Parts List)
2L011 SCREW, P-TIGHT 3X10 BIND HEAD+ GBCP3100
2L012 SCREW, P-TIGHT 3X10 BIND HEAD+ GBCP3100
2L021 SCREW, P-TIGHT M3X10 WASHER HEAD+ GCMP3100
2L022 SCREW, P-TIGHT M3X10 WASHER HEAD+
(See Electrical Parts List)
2L031 SCREW, S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L041 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L042 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L051 SCREW, S-TIGHT M3X5 BIND HEAD+ GBMS3050
2L099 SCREW, P-TIGHT M3X8 BIND HEAD+ GBCP3080
PACKING
S1 A GIFT BOX CARTON HG242BD 0VM306813
S1 B GIFT BOX CARTON HG454BD 1VM320020
S2 STYROFOAM(U27UK) HE471BD 0VM203890
S3 UNIT, BAG V4010PA 0VM406453B
S9 AC PAD HC461BD 0VM413331
ACCESSORIES
X1 REMOTE CONTROL UNIT 364/CZF29UU NA690ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG K8092BA 0VM404632
X20! A OWNER'S MANUAL(ENGLISH) HG242BD 0VMN04034
X20! B OWNER'S MANUAL(ENGLISH) HG454BD 0VMN04200
Ref. No. Mark Description Part No.
