FUNAI 29B-250 - Electrical Parts List

20040715 1-15-1 HG242EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a !
have special characteristics important to safety. Before
replacing any of these components, read carefully the
product safety notice in this service manual. Don't
degrade the safety of the product through improper ser-
vicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
29B-250
A
29B-750
B
Ref. No. Mark Description Part No.
A
B
MCV CBA
MCV CBA
Consists of the following:
0VSA15015
1VSA10027
MAIN CBA (MCV-A) ------------
B SUB JACK CBA (MCV-B) ------------
JACK CBA (MCV-C) ------------
SENSOR CBA 0VSA14893
Ref. No. Mark Description Part No.
MAIN CBA (MCV-A)
Consists of the following:
-----------
CAPACITORS
C002! METALLIZED FILM CAP. 0.068µF/275V K or CT2E683HJE06
! METALLIZED FILM CAP. 0.068µF/250V K CT2E683DC011
C003! SAFTY CAP. 2200pF/250V or CCN2EMA0E222
! SAFETY CAP. 2200pF/250V CA2E222MR049
C004 ELECTROLYTIC CAP. 33µF/400V M(L.Z) CA2H330NC010
C005 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103
C006 CERAMIC CAP. SL K 56pF/1KV or CCD3AKPSL560
CERAMIC CAP. SL J 56pF/1KV CCD3AJPSL560
C007 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C008 CERAMIC CAP.(AX) X K 5600pF/16V CCA1CKT0X562
C010 FILM CAP.(P) 0.022µF/50V J or CMA1JJS00223
FILM CAP.(P) 0.022µF/50V J CA1J223MS029
C011 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C012 ELECTROLYTIC CAP. 10µF/50V M H7 CE1JMAVSL100
C014 ELECTROLYTIC CAP. 470µF/35V M or CE1GMASDL471
ELECTROLYTIC CAP. 470µF/35V M CE1GMASTL471
C015 ELECTROLYTIC CAP. 47µF/25V M H7 CE1EMAVSL470
C017 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTL471
C018 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C020 ELECTROLYTIC CAP. 1000µF/16V M CE1CMZPTL102
C021 ELECTROLYTIC CAP. 470µF/10V M or CE1AMASDL471
ELECTROLYTIC CAP. 470µF/10V M CE1AMASTL471
C022 A ELECTROLYTIC CAP. 22µF/16V M H7 CE1CMAVSL220
C025 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C026 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C053 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMASSL221
C056 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C057 CHIP CERAMIC CAP.(1608) CH J 470pF/50V
or
CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C060 B ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C061 B CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
B CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
B CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C151 A CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
A CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
A CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C152 A CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
A CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
A CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C154 A CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
A CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
A CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C155 A ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C156 A ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C157 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C158 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C159 A CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
A CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
A CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C251 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C252 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C253 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C254 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C302 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C303 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C304 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C305 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
Ref. No. Mark Description Part No.
