20040715 2-7-1 HG242DPL
DECK PARTS LIST
Comparison Chart of Models and Marks
Model Mark
29B-250 A
29B-750 B
Ref. No. Mark Description Part No.
B2 A CYLINDER ASSEMBLY MK12.5 PAL 2HD
2SP
N2328CYL
B2 B CYLINDER ASSEMBLY MK12.5 PAL 6HD or N236ACYL
B CYLINDER ASSEMBLY MK12.5 PAL 6HD(V) N236BCYL
B3 LOADING MOTOR ASSEMBLY MK12.5 0VSA14636
B5 SLIDE PLATE MK12.5 0VM416429
B8 PULLEY ASSEMBLY(HI) MK12 0VSA13501
B9 MOVING GUIDE S P.P MK12.5 0VSA14717
B10 MOVING GUIDE T P.P MK12.5 0VSA14639
B11 LOADING ARM(TU) ASSEMBLY MK12 0VSA13300
B12 LOADING ARM(SP) ASSEMBLY MK12 0VSA13299
B31 AC HEAD ASSEMBLY MK12.5 0VSA14841
B35 TAPE GUIDE ARM ASSEMBLY MK12.5 0VSA15014
B37 CAPSTAN MOTOR 288/VCZC1301 N9681CML
B52 CAP BELT MK10 0VM411138
B73 FE HEAD(MK11) MH-131SF11 or DHVEC01Z0005
FE HEAD(MK12) VTR-1X2ERS11-155 or DHVEC01TE005
FE HEAD(MK12) HVFHP0047A DHVEC01AL007
B74 PRISM MK10 0VM202870
B86 B F BRAKE ASSEMBLY(HI) MK12 0VSA13447
B121 WORM MK12 0VM414091
B126 PULLEY MK12 0VM414330B
B133 IDLER ASSEMBLY(HI) MK12 0VSA13451
B148 TG CAP MK6 0VM407664C
B300 C DRIVE LEVER(TU) MK12 0VM203773
B303 F DOOR OPENER MK12 0VM203751C
B313 C DRIVE SPRING MK12 0VM414145
B347 GUIDE HOLDER A MK10 0VM304920
B354 SLIDER(TU) MK12 0VM101172F
B355 SLIDER(SP) MK12 0VM101182H
B359 CLEANER LEVER MK10 0VM304413
B360 CLEANER ROLLER MK9 0VM410032C
B361 CL POST MK10 0VM411114
B410 PINCH ARM(A) ASSEMBLY(6) MK12.5 or 0VSA14935
PINCH ARM(A) ASSEMBLY(5) MK12 0VSA13788
B411 PINCH SPRING MK12 0VM414644
B414 M BRAKE(SP) ASSEMBLY(HI) MK12 0VSA13655
B416 M BRAKE(TU) ASSEMBLY(HI) MK12 0VSA13449
B417 TENSION SPG(3002645) MK12.5 0VM414221G
B425 LOCK LEVER SPRING MK10 0VM411110
B482 CASSETTE PLATE MK12 0VM203749
B483 LOCK LEVER MK12 0VM414095
B487 BAND BRAKE(SP) MK12 0VM305723
B488 MODE LEVER(HI) MK12 or 0VM101175J
MODE LEVER(HI) MK12.5 0VM101352
B491 CAM GEAR(A)(HI) MK12 0VM101176
B492 MODE GEAR(LM) MK12 0VM204236
B494 C DOOR OPENER MK12 0VM305719
B499 T LEVER HOLDER MK12 0VM305729
B501 WORM HOLDER MK12 or 0VM203767
WORM HOLDER(R) MK12 0VM204324
B507 REEL WASHER MK9 5*2.1*0.5 0VM410058
B508 S BRAKE SPRING(HI) MK12 0VM414899
B513 P.S.W F 6*2.55*0.5 0VM402629A
B514 SCREW RACK MK10 0VM411535
B516 REEL WASHER MK9 5*2.1*0.5 0VM410058
B518 P.S.W CUT 1.6X4.0X0.5T 0VM408485A
B521 REV BRAKE SPG(HI) MK12 0VM414943
B522 TG POST ASSEMBLY MK10 0VSA11012
B525 LDG BELT MK11 0VM412804
B529 CLEANER ASSEMBLY MK10 0VSA11161
B551 FF ARM(HI) MK12 0VM306183
B553 REV SPRING MK11 0VM412555
B555 RACK ASSEMBLY MK12 0VSA13289
B557 MOTER PULLEY U5 0VM403205
B558 LOADING MOTOR M31E-1 R-14 7401 or MMDZB12MM007
LOADING MOTOR M31E-1 R-14 7402 MMDZB12MM008
B559 CLUTCH ASSEMBLY(HI) MK12 0VSA13450
B562 C DRIVE LEVER(SP) MK12 0VM203772
B563 SLIDER SHAFT MK12 0VM305762
B564 M GEAR(HI) MK12 0VM305755
B565 SENSOR GEAR(HI) MK12 0VM305756
B567 PINCH ARM(B) MK12 0VM305718
B568 BT ARM MK12 0VM305728
B571 P.S.W CUT 1.6X4.0X0.5T 0VM408485A
B572 P.S.W CUT 1.6X4.0X0.5T 0VM408485A
B573 REEL S MK11 0VM203436
B574 REEL T MK10 0VM202872C
B578 TR GEAR A MK10 0VM304440
B579 TR GEAR B MK12 0VM305900
B580 TR GEAR C MK12 0VM305743A
B581 CENTER GEAR MK11 0VM305081
B582 TR GEAR SPRING MK10 0VM411187C
B583 CAM WASHER MK12 0VM414741
B585 PSW(317505) MK11 0VM413663
B587 TENSION LEVER ASSEMBLY MK12 0VSA13279
B590 BRAKE ARM(TU) MK12 0VM203752E
B591 BAND BRAKE(TU) MK12 0VM305724C
B592 TG POST MK10 0VM411108E
L1051 SCREW, B-TIGHT M2.6X6 PAN HEAD+ GPMB9060
L1053 SCREW, S-TIGHT M2.6X8 WASHER HEAD+ GCMS9080
L1151 SCREW, SEMS M2.6X4 PAN HEAD+ CPM39040
L1191 SCREW, S-TIGHT M2.6X8 WASHER HEAD+ GCMS9080
L1321 SCREW, S-TIGHT M3X6 BIND HEAD+ GBMS3060
L1322 SCREW, B-TIGHT M2.3X4 BIND HEAD+ GBMBY040
L1341 SCREW, P-TIGHT M2X6 PAN HEAD+ GPMP2060
L1406 AC HEAD SCREW MK9 0VM410964
L1450 SCREW, SEMS M2.6X5 PAN HEAD+ CPM39050
L1466 SCREW, S-TIGHT M2.6X6 BIND HEAD+ GBMS9060
L1467 SCREW M2.6X5 WASHER HEAD+ SCM39050
Ref. No. Mark Description Part No.
