FUNAI 29B-250 - Page 40

1-11-3 HG242PIN
Notes:
Abbreviation for Active Level:
PWM -----Pulse Wide Modulation
A/D--------Analog - Digital Converter
90 IN
D-PFG
Drum Motor
Pulse
Generator
PULSE
91 -
AMPVREF
OUT
V-Ref for CTL
AMP
-
92 -
AMPVREF
in
V-Ref for CTL
AMP
-
93 -
P80/C P80/C Terminal
-
94
IN/
OUT
CTL (-)
Playback/
Record Control
Signal (-)
H/L
95
IN/
OUT
CTL (+)
Playback/
Record Control
Signal (+)
H/L
96 -
AMPC
CTL AMP
Connected
Terminal
-
97 -
CTLAMP
out
To Monitor for
CTL AMP
Output
PULSE
98 -
AMPVcc AMPVcc
-
99 -
AVcc
A/D Converter
Power Input/
Standard
Voltage Input
-
100 IN
AGC
IF AGC
Comparator
Signal
A/D
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
