FUNAI 29B-250 - Page 49

20040715 1-15-4 HG242EL
C518 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C519 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C520 CHIP CERAMIC CAP.(1608) CH J 100pF/50V
or
CHD1JJ3CH101
CHIP CERAMIC CAP.(1608) CG J 100pF/
50V
CHD1JJ3CG101
C521 CHIP CERAMIC CAP. CH J 560pF/50V or CHD1JJ3CH561
CHIP CERAMIC CAP. CG J 560pF/50V CHD1JJ3CG561
C522 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C523 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C524 CHIP CERAMIC CAP. CH J 330pF/50V or CHD1JJ3CH331
CHIP CERAMIC CAP. CG J 330pF/50V CHD1JJ3CG331
C526 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C527 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C528 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C530 CERAMIC CAP.(AX) F Z 0.022µF/25V CCA1EZTFZ223
C531 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C532 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C533 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C535 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C538 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C540 B ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
B ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C561 B CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
B CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C562 B ELECTROLYTIC CAP. 330µF/6.3V M H7 CE0KMASSL331
C563 CHIP CERAMIC CAP. F Z 1µF/10V or CHD1AZB0F105
CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C564 CHIP CERAMIC CAP.(1608) CH J 100pF/50V
or
CHD1JJ3CH101
CHIP CERAMIC CAP.(1608) CG J 100pF/
50V
CHD1JJ3CG101
C567 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C701 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C702 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C704 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C706 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C708 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C709 A ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C710 A CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C715 A CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
Ref. No. Mark Description Part No.
C716 B CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
B CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
C717 B CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
B CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
C756 B CHIP CERAMIC CAP.(1608) CH J 470pF/50V
or
CHD1JJ3CH471
B CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C757 B CHIP CERAMIC CAP.(1608) CH J 470pF/50V
or
CHD1JJ3CH471
B CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C851 CHIP CERAMIC CAP.(1608) CH J 22pF/50V
or
CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C852 CHIP CERAMIC CAP.(1608) CH J 22pF/50V
or
CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C853 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C854 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C855 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C856 CHIP CERAMIC CAP. CH J 180pF/50V or CHD1JJ3CH181
CHIP CERAMIC CAP. CG J 180pF/50V CHD1JJ3CG181
C859 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C862 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
CONNECTOR
CN701 B AFV PCB ASSEMBLY CPU2900/G471 HG471AFV
DIODES
D001 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D002 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D003 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D004 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D005 RECTIFIER DIODE BA159 NDQZ000BA159
D006 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D007 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D008 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D009 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D011 RECTIFIER DIODE BA158 NDQZ000BA158
D012 RECTIFIER DIODE FR202-B/P NDQZ000FR202
D013 RECTIFIER DIODE FR202-B/P NDQZ000FR202
D014 A SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
A SCHOTTKY BARRIER DIODE ERB81-004 AERB81004***
D014 B SCHOTTKY BARRIER DIODE SB340 NDQZ000SB340
D015 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D016 A RECTIFIER DIODE BA158 NDQZ000BA158
D018 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D019 ZENER DIODE DZ-6.8BSBT265 or NDTB0DZ6R8BS
ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D021 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D023 A ZENER DIODE DZ-5.1BSBT265 or NDTB0DZ5R1BS
Ref. No. Mark Description Part No.
