FUNAI DR-C3835 - Page 13

1-5-3 E7B20DC
3. How to Eject Manually
Note: When rotating the gear, be careful not to damage the gear.
1. Remove the TOP COVER.
2. Rotate the gear in the direction of the arrow manually as shown below until the tray descends.
3. Pull the tray out manually and remove a disc.
A
View for A
Rotate this gear in
the direction of the arrow
