FUNAI DR-C3835 - MECHANICAL PARTS LIST

20060331 1-16-1 E7B22CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
DR-C3835 A
DR-B3737 B
Ref. No. Mark Description Part No.
A1X A FRONT ASSEMBLY E7B20ED 1VM322437
A1X B FRONT ASSEMBLY E7B25BD 1VM322451
A2 TOP COVER(R3 PAL) E7B70ED 1VM120917
A3 A REAR PANEL E7B22FD 1VM221989
A3 B REAR PANEL E7B25BD 1VM221992
A4 CHASSIS E6700ED 1VM120045A
A5 FOOT K7010UA 0VM403657A
A6 FAN COVER E6800ED 1VM220260
A13 BARCODE LABEL UNFIGURE E9704ED ----------
A13 A BARCODE LABEL E7B22FD ----------
A13 B BARCODE LABEL E7B25BD ----------
2B1 PCB HOLDER E7A00UD 1VM220926
2B2 CABLE COVER E7A00UD 1VM422494
2B4 LOCKING CARD SPACER KGLS-22S XP0U039WD001
2B5 POWER EARTH PLATE E6800ED 1VM420990
2B9 POWER HOLDER E7B20ED 1VM322117
2B13 PLATE GROUND(RCA) E6800ED 1VM320610
2B15 FAN EARTH E6800ED 1VM320812
FM1001 MOTOR DC FAN D05U-12TS1 09(UX) or MMEZL12NH008
MOTOR DC FAN D05020090-1 MMEZR12SNN08
2L011 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L012 SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
2L013 SCREW P-TIGHT M3X8 BIND HEAD+
BLK
GBHP3080
2L021 SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
2L031 SCREW S-TIGHT M3X10 BIND HEAD+ GBJS3100
2L081 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
PACKING
S1 A GIFT BOX CARTON E7B22FD 1VM322384
S1 B GIFT BOX CARTON E7B25BD 1VM322387
S2 STYROFORM(UK) E6821BD 1VM220397C
S3 UNIT BAG E5500UD 0VM411683
S4 B AC PAD HC461BD 0VM413331
ACCESSORIES
X1 REMOTE CONTROL UNIT NB078ED NB078ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY R6UW/2S or XB0M311MS001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X4 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X5 ACCESSORY BAG E5700UD 0VM415576
X6 B QUICK GUIDE E7B25BD 1VMN22309
X6A A QUICK GUIDE(FR) E7B22FD 1VMN22275
X6B A QUICK GUIDE(IT) E7B22FD 1VMN22930
X6C A QUICK GUIDE(GE) E7B22FD 1VMN22931
X7 21P CABLE(BYR SUPPLY) H9300ED 0VMN03276
X10! B OWNERS MANUAL E7B25BE 1VMN22308
X10A! A OWNERS MANUAL(FR) E7B22FD 1VMN22274
X10B! A OWNERS MANUAL(IT) E7B22FD 1VMN22908
X10C! A OWNERS MANUAL(GE) E7B22FD 1VMN22909
Ref. No. Mark Description Part No.
