FUNAI DR-C3835 - ELECTRICAL PARTS LIST

20060331 1-17-1 E7B22EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
DVD MECHANISM & DVD MAIN CBA
ASSEMBLY
AV ASSEMBLY
AV CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
DR-C3835 A
DR-B3737 B
Ref. No. Mark Description Part No.
A
B
DVD MECHANISM & DVD MAIN CBA
ASSEMBLY
DVD MECHANISM & DVD MAIN CBA
ASSEMBLY
N78G1CFN
N78G2CBN
Ref. No. Mark Description Part No.
A
B
AV ASSEMBLY
AV ASSEMBLY
Consists of the following:
1VSA14352
1VSA14357
AV CBA (SUB-A)
SW CBA (SUB-B)
----------
----------
Ref. No. Mark Description Part No.
AV CBA (SUB A)
Consists of the following:
----------
CAPACITORS
C1151 ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTM100
C1152 ELECTROLYTIC CAP. 47µF/ 16V M or CE1CMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
16V M
CE1CMASTM470
C1153 ELECTROLYTIC CAP. 100µF/ 16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/ 16V M CE1CMASTM101
C1154 ELECTROLYTIC CAP. 220µF/ 16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/ 16V M CE1CMASTM221
C1155 CERAMIC CAP.(AX) F Z 0.1µF/ 50V CCA1JZTFZ104
C1160 ELECTROLYTIC CAP. 47µF/ 16V M or CE1CMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
16V M
CE1CMASTM470
C1163 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1164 ELECTROLYTIC CAP. 100µF/ 16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/ 16V M CE1CMASTM101
C1167 ELECTROLYTIC CAP. 100µF/ 6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/ 6.3V M CE0KMASTM101
C1168 ELECTROLYTIC CAP. 47µF/ 16V M or CE1CMASDL470
ALUMINUM ELECTROLYTIC CAP 47µF/
16V M
CE1CMASTM470
C1173 ELECTROLYTIC CAP. 100µF/ 6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/ 6.3V M CE0KMASTM101
C1174 ELECTROLYTIC CAP. 100µF/ 6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/ 6.3V M CE0KMASTM101
C1175 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTM471
C1176 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1177 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1202 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1203 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1206 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1207 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1208 ELECTROLYTIC CAP. 220µF/ 16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/ 16V M CE1CMASTM221
C1209 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1210 ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTM100
C1211 ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTM100
C1212 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C1213 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C1215 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1216 ELECTROLYTIC CAP. 100µF/ 6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/ 6.3V M CE0KMASTM101
C1218 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTM471
C1221 ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTM100
C1222 ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTM100
C1223 CHIP CERAMIC CAP.(1608) CH J 270pF/
50V
CHD1JJ3CH271
C1224 CHIP CERAMIC CAP.(1608) CH J 270pF/
50V
CHD1JJ3CH271
C1225 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C1226 CHIP CERAMIC CAP.(1608) CH J 47pF/
50V
CHD1JJ3CH470
C1227 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1228 ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTM100
C1229 ELECTROLYTIC CAP. 10µF/ 16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/ 16V M CE1CMASTM100
Ref. No. Mark Description Part No.
