FUNAI LT6-M32BB - Page 14

4-3 A8CF0DC
[6] Shield Box
[8] Shield (T)
[5] FFC Shield
[7] Digital Main CBA Unit
(S-13)
(S-14)
(S-12)
(S-7)
(S-14)
(S-14)
[9] Power Supply CBA
[10] Junction-B CBA
(S-10)
(S-11)
(S-9)
(S-10)
(S-9)
(S-8)
Connector IC Card OSU
Fig. D2
