FUNAI LT6-M32BB - Specifications; Tuner, LCD Panel, DVB-T, Video, Audio Specifications

1-1 A8CF0SP
SPECIFICATIONS
< TUNER >
VHS/UHF Input ----------- 75Ω unbal., IEC Connector
Center IF ------------------- SECAM-L 38.9MHz, SECAM-L’ 33.9MHz
< LCD PANEL >
<DVB-T>
*1: modulation parameters = [8k 64QAM CR=2/3 GI=1/32]
*2: modulation parameters = [2k 64QAM CR=2/3 GI=1/32]
*3: modulation parameters = [2k 16QAM CR=3/4 GI=1/32]
< VIDEO >
Description Condition Unit Nominal Limit
1. Video S/N 80 dB --- 40
2. Audio S/N --- dB --- 40/40
Description Condition Unit Nominal Limit
1. Number of Pixels
Horizontal
Ver tical
pixels
pixels
1366
768
---
---
2. Viewing Angle
Horizontal
Ver tical
°
°
-88 to 88
-88 to 88
---
---
Description Condition Unit Nominal Limit
1. RECEIVED
FREQ.RANGE
(-60dBm, 45ch.) *1
+
-
kHz
kHz
T.B. D
T.B. D
500
-150
2. INPUT DYNAMIC
RANGE (mix./max) *1
VHF HIGH 7ch.
UHF 45ch.
dBm
dBm
T.B. D
T.B. D
-75/-10
-75/-10
3. C/N PERFORMANCE
*1
VHF HIGH 7ch.
UHF 45ch.
dB
dB
T.B. D
T.B. D
≦18
≦18
4. MULTIPATH
a. Performance with
short delay echoes
b. Performance with
long delay echoes
c. C/N Performance on
0dB echo channel
(14µs)
UHF 45ch.
c:*2
d:*3
c:*2
d:*3
c:*1
dB
dB
dB
dB
dB
T.B. D
T.B. D
T.B. D
T.B. D
T.B. D
≦23
≦20
≦23
≦18
≦24
Description Condition Unit Nominal Limit
1. Over Scan
Horizontal
Vertical
%
%
5
5
±5
±5
2. Color Temperature
AT 70% WHITE FIELD
x
y
°K 12000
0.272
0.278
---
±0.005
±0.005
3. Resolution
Horizontal
Vertical
line
line
400
350
---
---
4. Brightness AT 100% WHITE FIELD cd/m
2
320 ---
