MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1 FRONT CABINET A8CF0EP 1EM022605
A3 CONTROL PLATE A8CF0EP 1EM426278
A4 REAR CABINET A8CF0EP 1EM022485
A5 DECORATION PLATE A8AF0UH 1EM122277
A7 FUNCTION KNOB A8CF0EP 1EM426339
A9 STAND COVER A8AF0UH 1EM022087A
A10 REAR COVER A73F0EP 1EM322722
A11 LED LENS A8AF0UH 1EM323597
A12 STAND RUBBER FOOT L5001CB 1EM423855
B3 SHIELD BOX A8CF0EP 1EM122233
B4 SHIELD (T) A8CF0EP 1EM324059A
B7 STAND BASE PLATE A8AF0UH 1EM122276
B8 STAND HINGE A8AF0UH 1EM323598
B10 STAND HOLDER A81N0UH 1EM322709
B11 SPEAKER HOLDER (L) A8CF0EP 1EM324397
B12 SPEAKER HOLDER (R) A8CF0EP 1EM324398
B22 CLOTH(10X180XT0.5) L0336JG 0EM408827
B30 GASKET A8AF0UH 1EM425861
B41 FFC SHIELD A8CF0EP 1EM324060
CL101A WIRE ASSEMBLY FFC A-D 25PIN 25PIN/50MM WX1A8CF0-002
CL102A WIRE ASSEMBLY FFC A-D 25PIN 25PIN/50MM WX1A8CF0-002
CL103A WIRE ASSEMBLY FFC A-D 23PIN 23PIN/50MM WX1A8CF0-003
CL104A WIRE ASSEMBLY FFC A-D 25PIN 25PIN/50MM WX1A8CF0-002
CL801 WIRE ASSEMBLY SPEAKER 2PIN 2PIN/
190MM
WX1A8CF0-004
CL802 WIRE ASSEMBLY SPEAKER 2PIN 2PIN/
190MM
WX1A8CF0-004
CN3802 CONNECTOR IC CARD OSU SLOT 2013858-1 J620680AP001
L2 SCREW P-TIGHT M4X14 BIND HEAD+BLK GBHP4140
L4 SCREW P-TIGHT M3X12 DISH HEAD+ GDJP3120
L6 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L10 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L19 HEX SCREW #4-40 7MM 1EM422042
L21 DOUBLE SEMS SCREW M2X10+ M2X10 FPJ32100
L22 SEMS M2X4 M2X4 + FPJ32040
LCD1 LCD MODULE PAL LCD 32INCH PAL UG320EA
SP801 SPEAKER MAGNETIC S0412F08 DSD1609XQ001
SP802 SPEAKER MAGNETIC S0412F08 DSD1609XQ001
PACKING
S4 SET BAG L4300UA 1EM321546
S16 STAND BAG A71FCUH 1EM425338
ACCESSORY
X3 REMOTE CONTROL NF028RD 170/
ECPLC6.501/NF028
NF028RD
Ref. No. Description Part No.
A6! RATING LABEL A8CF0EP ----------
A21 POP LABEL A8CN1EP ----------
A27 CARD LABEL A8CN0FP ----------
B43 GASKET A71F0UH 1EM424393
L2 SCREW P-TIGHT M4X14 BIND HEAD+BLK GBHP4140
L6 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L9 SCREW S-TIGHT M3X4 BIND HEAD+BLK GBHS3040
L10 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L15 DOUBLE SEMS SCREW M4X10 + BLK FPH34100
L17 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392A
L23 DOUBLE SEMS SCREW D9 M3X6 1EM426817
PACKING
S1 CARTON A8CF0EP 1EM426437
S2 STYROFOAM TOP A8CF0EP 1EM022666
S3 STYROFOAM BOTTOM A8CF0EP 1EM022665
S5 SERIAL NO. LABEL L9750UA ----------
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X4 BATTERY R6RC/2P XB0M601MS001
X5 SCREW BAG A81N0UH 1EM424596A
X2-1! OWNERS MANUAL(DE-6) A8CF0EP 1EMN23487
X2-2! OWNERS MANUAL(FR-6) A8CF0EP 1EMN23488
X2-3! OWNERS MANUAL(PL-6) A8CF0EP 1EMN23489
! OWNERS MANUAL(AR) 1EMN23490
! OWNERS MANUAL(BG) 1EMN23491
! OWNERS MANUAL(EN) 1EMN23492
! OWNERS MANUAL(RU) 1EMN23493
! OWNERS MANUAL(UA) 1EMN23494
Ref. No. Description Part No.
