MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
STAND COVER ASSEMBLY A03P0EZ 1ESA23066
A1 FRONT CABINET A03P0EP 1EM025222A
A2 KNOB FRAME A03P0EP 1EM223824
A3 DECORATION PLATE A03P1EP 1EM024908B
A4 REAR CABINET A03P1EP 1EM024910
A6 JACK HOLDER(HP) A03A0EP 1EM326877
A8! RATING LABEL A03P3PH ----------
A9 FUNCTION KNOB A03P0EP 1EM223825
A10 POP LABEL A03P1EP ----------
A11 JACK HOLDER A93F0FP 1EM123494A
A12 STAND SUB COVER A03P0EP 1EM327558
B1 SHIELD BOX A03A0EP 1EM223605
B2 TUNER SHIELD A03A0EP 1EM223604
B3 STAND BRACKET A03P0EP 1EM124196A
B4 WALL MOUNT BRACKET(L) A03P0EP 1EM124193
B5 WALL MOUNT BRACKET(R) A03P0EP 1EM124194
B6 SPEAKER HOLDER A01P0UH 1EM124113
B7 PCB HOLDER A03P0EP 1EM124195
B8 AC INLET HOLDER A01P0UH 1EM327037
B14 STAND HINGE A01P0UH 1EM124035
B15 CLOTH 10X150XT1.0 1EM421092
B17 GASKET A8AF0UH 1EM425861
B18 RUBBER CUSHION A03P0EP 1EM432477
B19 CLOTH(B) L5201U0 15X10X1.0T 0EM400076
B20 GASKET A91H2UH 1EM428597
CL401 WIRE ASSEMBLY 29PIN FFC 29PIN 50MM WX1A94F0-101
CL402 WIRE ASSEMBLY 29PIN FFC 29PIN 50MM WX1A94F0-101
CL403 WIRE ASSEMBLY 29PIN FFC 29PIN 50MM WX1A94F0-101
CL404 WIRE ASSEMBLY 29PIN FFC 29PIN 50MM WX1A94F0-101
CL452 WIRE ASSEMBLY 4-6PIN 4-6PIN/280MM/
AWG24/U
WX1A03P0-204
CL453 WIRE ASSEMBLY 7PIN FFC 7PIN/50MM WX1A03A0-102
CL601 WIRE ASSEMBLY 2PIN 2PIN/120MM/AWG18/
UL1
WX1A03P0-304
CL801 WIRE ASSEMBLY 2PIN 2PIN/400MM/AWG24/
UL1
WX1A03P0-203
CL802 WIRE ASSEMBLY 2PIN 2PIN/310MM/AWG24/
UL1
WX1A03P0-202
CL1852 WIRE ASSEMBLY 14PIN 14PIN/230MM/
AWG24/UL
WX1A03P0-201
CL3903 WIRE ASSEMBLY 51-51PIN LVDS 51-51PIN/
320MM/AWG32
WX1A03P0-401
L1 SCREW P-TIGHT M4X14 BIND HEAD+BLK GBHP4140
L2 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L4 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L6 ASSEMBLED SCREW ( D9 M3X6 ) A71F0UH 1EM424392B
L7 DOUBLE SEMS SCREW M5X12 BLK
M5X12PAN HEAD +BLK
FPH35120
L8 S-TIGHT SCREW M3X6 BIND HEAD+BLACK GBHS3060
L9 HEX SCREW #4-40 7MM 1EM430139
L10 SCREW S-TIGHT 3X8 WASHER HEAD+BLAC GCHS3080
L13 SCREW SEMS M4X8 PAN HEAD + FPJ34080
L15 DOUBLE SEMS SCREW M5X8 M5X8 PAN
HEAD+
FPJ35080
L16 SCREW S-TIGHT M4X5 BIND HEAD+ GBJS4050
L17 SCREW TAP TIGHT M3X10 BIND HEAD+BLK
NI
GBHS3100
L18 SCREW P-TIGHT 3X12 BIND HEAD+ BLK GBHP3120
L24 SHOULDER SCREW A01Q0UF 1EM328277
LCD-1 LCD MODULE 40W LTA40OHM01 UDULCD0SM006
SP801 SPEAKER MAGNETIC SO412F24 DS08120XQ003
SP802 SPEAKER MAGNETIC SO412F24 DS08120XQ003
X803 THERMOSTAR TMS-L-2(12*12HC) XK10000X4003
X3301 THERMOSTAR TMS-L-2(12*12HC) XK10000X4003
PACKING
S1 CARTON(U) A03P3PH 1EM329997
S2 STYROFOAM TOP A03P3PH 1EM027036
S3 STYROFOAM BOTTOM A03P3PH 1EM027037
S4 CARTON(L) A03P3PH 1EM329998
S5 SET BAG A03P0EP 1EM327238
S6 SERIAL NO. LABEL L9750UA ----------
S9 STAND BAG A91H2UH 1EM428517
ACCESSORY
AC601! CORD W/O A GND WIRE CB/162/NO/BLACK or WAE0162LW003
! CORD W/O A GND WIRE CEE/152/NO/BLACK WAE152ZHN001
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2! OWNERS MANUAL A03P3PH 1EMN27260
X3 REMOTE CONTROL NF036RD 170/
ECPLC6.501/NF036
NF036RD
X4 MANGANESE DRY BATTERY R6UWC/2SK or XB0M311MS002
DRY BATTERY ES-GR6M-C XB0M571GLP01
X5 STAND SCREW KIT A03P3PH 1ESA27089
Ref. No. Description Part No.
To Next Page
