FUNAI LT8-M40BB - Electrical Parts List

20101209 15-1 A03P3EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DIGITAL MAIN CBA UNIT
POWER SUPPLY ASSEMBLY
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A03P3MMA-001
Ref. No. Description Part No.
POWER SUPPLY ASSEMBLY
Consists of the following:
A03P3MPW-001
POWER SUPPLY CBA
JACK CBA
----------
----------
Ref. No. Description Part No.
POWER SUPPLY CBA
Consists of the following:
----------
CAPACITORS
C11 CHIP CERAMIC CAP. CH J 15pF/50V CHD1JJ3CH150
C12 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C16 CHIP CERAMIC CAP.(1608) CH J 47pF/50V CHD1JJ3CH470
C18 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C19 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C20 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C22 CHIP CERAMIC CAP.(1608) CH J 47pF/50V CHD1JJ3CH470
C24 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C27 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C28 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C31 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C33 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω or RRXA000YF002
RES CHIP 1608 1/10W 0 Ω RRJ000WAL002
C34 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω or RRXA000YF002
RES CHIP 1608 1/10W 0 Ω RRJ000WAL002
C35 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C36 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C37 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C38 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C181 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C182 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C204 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C205 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C206 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C207 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C213 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C214 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C215 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C216 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C217 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C222 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C223 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C301 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω or RRXA000YF002
RES CHIP 1608 1/10W 0 Ω RRJ000WAL002
C302 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C303 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C304 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω or RRXA000YF002
RES CHIP 1608 1/10W 0 Ω RRJ000WAL002
C305 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C306 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C307 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C308 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C309 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C310 ELECTROLYTIC CAP. 470µF/10V M CE1AMASDL471
C311 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C312 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω or RRXA000YF002
RES CHIP 1608 1/10W 0 Ω RRJ000WAL002
C313 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C314 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C315 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω or RRXA000YF002
RES CHIP 1608 1/10W 0 Ω RRJ000WAL002
C316 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C317 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C318 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C319 ELECTROLYTIC CAP. 470µF/10V M CE1AMASDL471
C320 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C323 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C324 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C401 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C402 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C403 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C404 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C421 CHIP CERAMIC CAP.(1608) CH D 10pF/50V or CHD1JD3CH100
CHIP CERAMIC CAP.(1608) CH J 10pF/50V CHD1JJ3CH100
C452 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C454 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C456 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C502 ELECTROLYTIC CAP. 2200µF/25V M or CE1EMZPDL222
ELECTROLYTIC CAP. 2200µF/25V M CE1EMZNDL222
C503 ELECTROLYTIC CAP. 2200µF/25V M or CE1EMZPDL222
ELECTROLYTIC CAP. 2200µF/25V M CE1EMZNDL222
C504 ELECTROLYTIC CAP. 100µF/25V M CE1EMASDL101
C505 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C507 CAP ELE STD-85 4700µF 6.3V SL or CE0KMZNDL472
ELECTROLYTIC CAP. 4700µF/6.3V SM or CE0KMZPDL472
CAP ELE 4700µF/6.3V/M/85 or CEA472KSN002
CAP ELE 4700µF/6.3V/M/85 CEA472TEP002
C508 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C509 CERAMIC CAP. 1500pF/2KV or CA3D152PAN04
CERAMIC CAP RB 1500pF/2KV or CA3D152TE006
CERAMIC CAP. BL 1500pF/2KV CA3D152XF003
C511 ELECTROLYTIC CAP. 220µF/50V M or CE1JMZADL221
ELECTROLYTIC CAP 220µF/50V M CE1JMZPDL221
C514 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
