20101209 15-10 A03P3EL
INVERTER ASSEMBLY
INVERTER POWER CBA
Ref. No. Description Part No.
INVERTER ASSEMBLY
Consists of the following:
A03P3M1V-001
INVERTER POWER CBA
FUNCTION CBA
IR SENSOR CBA
----------
----------
----------
Ref. No. Description Part No.
INVERTER POWER CBA
Consists of the following:
----------
CAPACITORS
C1801 CAP CERAMIC (AX) 0.1µF/50V/F/Z CA1J104TU062
C1802 CERAMIC CAP. 330pF/2KV or CA3D331PAN04
CERAMIC CAP. RB 330pF/2KV or CA3D331TE006
CERAMIC CAP. BL 330pF/2KV CA3D331XF003
C1803 CERAMIC CAP. 330pF/2KV or CA3D331PAN04
CERAMIC CAP. RB 330pF/2KV or CA3D331TE006
CERAMIC CAP. BL 330pF/2KV CA3D331XF003
C1804 ELECTROLYTIC CAP. 100µF/25V M CE1EMASDL101
C1805 CAP CERAMIC (AX) 4700pF/50V/B/K CA1J472TU061
C1806 CERAMIC CAP. B K 100pF/1KV or CCD3AKD0B101
CERAMIC CAP. B K 100pF/1KV or CA3A101MR028
CERAMIC CAP. B K 100pF/1KV or CCD3AKN0B101
CERAMIC CAP. B K 100pF/1KV CCD3AKQ0B101
C1807 POLYESTER FILM CAP. (PB FREE) 0.1µF/100V
J or
CA2A104DT018
CAP POLYESTER FILM 0.1µF/100V J or CA2A104SER02
CAP POLYESTER FILM 0.1µF/100V/J/PCMT or CTA104PKR003
POLYESTER FILM CAP. 0.1µF/100V J or CMB104EUR001
POLYESTER FILM CAP. (PB FREE) 0.1µF/100V
J
CA2A104DT026
C1808 CAP CERAMIC (AX) 0.1µF/50V/F/Z CA1J104TU062
C1809 CERAMIC CAP.(AX) B K 330pF/50V or CCA1JKT0B331
CAP CERAMIC (AX) 330pF/50V/B/K CA1J331TU061
C1810 CAP CERAMIC (AX) 0.1µF/50V/F/Z CA1J104TU062
C1811 METALIZED POLYESTER FILM CAP. 0.47µF/
50V J or
CT1J474DT040
METALIZED POLYESTER FILM CAP. 0.47µF/
63V J or
CT1K474SER01
CAP POLYESTER FILM 0.47µF/63V/J/PCMT CTA474PKR002
C1812 CAP CERAMIC (AX) 0.1µF/50V/F/Z CA1J104TU062
C1813 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C1814 CAP METALIZED FILM J0.039µF/630V/J/MPEF
or
CA2K393DT045
CAP METALIZED FILM 0.039µF/630V/J CTA393PKR004
C1815 CAP CERAMIC (AX) 4700pF/50V/B/K CA1J472TU061
C1816 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1817 CAP CERAMIC (AX) 0.01µF/50V/F/Z CA1J103TU062
C1818 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1819 SAFTY CAP. 2200pF/250V KX or CA2E222MR101
SAFETY CAP. 2200pF/250V M CCN2HMN0E222
C1821 CAP ELECTROLYTIC 330µF/400V/M/30/35 or CA2H331DYG10
ELECTROLYTIC CAPACITOR 330µF/400V CA2H331NC226
C1834 ELECTROLYTIC CAP. 100µF/25V M CE1EMASDL101
C1851 CAP ELE 4700/35V/M/85/D22XL2 CEA472KSN004
C1852 CAP ELE 4700/35V/M/85/D22XL2 CEA472KSN004
C1853 CAP CERAMIC (AX) 0.1µF/50V/F/Z CA1J104TU062
C1854 CAP ELE 4700/35V/M/85/D22XL2 CEA472KSN004
C1858 ELECTROLYTIC CAP. 2200µF/35V M or CE1GMZNDL222
ELECTROLYTIC CAP. 2200µF/35V M or CE1GMZPDL222
CAP ELE 2200µF/35V/M/85 or CEE222KSN002
CAP ELE 2200µF/35V/M/85 CEE222TEP002
C1859 ELECTROLYTIC CAP. 2200µF/35V M or CE1GMZNDL222
ELECTROLYTIC CAP. 2200µF/35V M or CE1GMZPDL222
CAP ELE 2200µF/35V/M/85 or CEE222KSN002
CAP ELE 2200µF/35V/M/85 CEE222TEP002
C1863 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1871 CAP CERAMIC (AX) 0.01µF/50V/F/Z CA1J103TU062
C1872 POLYESTER FILM CAP. (PB FREE) 0.047µF/
100V J or
CA2A473DT018
CAP POLYESTER FILM 0.047µF/100V J or CA2A473SER02
CAP POLYESTER FILM 0.047µF/100V/J/PCMT
or
CTA473PKR003
POLYESTER FILM CAP. 0.047µF/100V J or CMB473EUR001
POLYESTER FILM CAP. (PB FREE) 0.047µF/
100V J
CA2A473DT026
C1882 CAP CERAMIC (AX) 0.01µF/50V/F/Z CA1J103TU062
C1883 CAP CERAMIC (AX) 0.01µF/50V/F/Z CA1J103TU062
CONNECTORS
CN1801! CONNECTOR PRINT OSU 3 S B3P4-VH-L or J3VH030JG015
! CONNECTOR PRINT OSU 03/S/JS-1120-
04N03
J3JT03CHY005
CN1810! CONNECTOR B2P3-VH(LF)(SN) or J3VH020JG001
! CONNECTOR PRINT OSU 02/S/JS-1120-
03N02
J3JT02CHY004
CN1851 FPC/FFC CONNECTOR IMSA-9615S-07A-PP-
A or
JC96J07ER007
CONNECTOR PRINT MES 07 S 1.0-11-7P or JC1107JSH001
CONNECTOR PRINT MES 00 6232 007 006
800+
JC62G07UG026
CN1852 CONNECTOR PRINT OSU B14B-PH-K-
S(LF)(SN) or
J3PHC14JG029
CONNECTOR PRINT OSU JS-1125-14(K) or J3JT14CHY001
CONNECTOR PRINT OSU C S 1-440054-4 J344C14AP001
DIODES
D1803 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E or QDTZ0HSS4148
DIODE SWITCHING 1N4148-F0021 NDTZ01N4148F
D1804 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E or QDTZ0HSS4148
DIODE SWITCHING 1N4148-F0021 NDTZ01N4148F
D1805 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E or QDTZ0HSS4148
DIODE SWITCHING 1N4148-F0021 NDTZ01N4148F
D1806 SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1807 SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1808 DIODE ZENER 4V7BSB-T26 or NDTB4R7BST26
DIODE ZENER HZS4.7NB2TE-EQ QDTB0HZS4R7N
D1809 DIODE ZENER 27BSB-T26 or NDTB027BST26
DIODE ZENER HZS27NB2TE-EQ QDTBHZS27NB2
D1810 DIODE ZENER 18BSB-T26 or NDTB018BST26
DIODE ZENER HZS18NB2TE-EQ QDTBHZS18NB2
D1811 DIODE ZENER 15BSB-T26 or NDTB015BST26
DIODE ZENER HZS15NB2TE-EQ QDTBHZS15NB2
D1851 DIODE SHOTTKY FCHS20A08 QDWZCHS20A08
D1852 DIODE SHOTTKY FCHS20A08 QDWZCHS20A08
D1853 DIODE ZENER 13BSB-T26 or NDTB013BST26
ZENER DIODE MTZJT-7713B or QDTB00MTZJ13
DIODE ZENER DO-34 MTZJ13B or NDTB00MTZJ13
DIODE ZENER HZS13NB2TE-EQ QDTBHZS13NB2
D1855 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E or QDTZ0HSS4148
DIODE SWITCHING 1N4148-F0021 NDTZ01N4148F
D1871 DIODE ZENER 20BSB-T26 or NDTB020BST26
DIODE ZENER HZS20NB2TE-EQ QDTBHZS20NB2
D1872 DIODE ZENER 27BSB-T26 or NDTB027BST26
DIODE ZENER HZS27NB2TE-EQ QDTBHZS27NB2
D1873 IC SHUNT REGULATOR KIA431-AT/P or NSZBA0TJY036
IC SHUNT REGULATOR SL431A-AT or NSZBA0TAUK01
IC SHUNT REGULATOR AS431BZTR-E1 NSZBA0TBCD01
D1891 WIRE COPPER 6111-06003-0120 or XZ40C0SHG002
WIRE COPPER JP0.6MM XZ40C0AKM001
ICS
IC1801 IC 0V-SWITCHING RESONANT CONVE
TEA1611T/N1.518
NSCA0TNXP002
IC1831! PHOTO COUPLER PS2561L1-1-A-V(L) QPEL561L11AV
IC1832! PHOTO COUPLER PS2561L1-1-A-V(L) QPEL561L11AV
Ref. No. Description Part No.
