FUNAI LT8-M40BB - Page 69

20101209 15-12 A03P3EL
FUNCTION CBA
IR SENSOR CBA
R1880 RES CARBON FILM T 1/4W G 3.3k Ω or RCX4332T1002
RES CARBON FILM 1/4W G 3.3k Ω RCG332PAK001
R1881 RES CARBON FILM 1/4W J 2.7k Ω or RCX4272FS002
RES CARBON FILM T 1/4W J 2.7k Ω RCX4272T1001
R1886 RES CARBON FILM T 1/4W J 390 Ω or RCX4391T1001
RES CARBON FILM 1/4W J 390 Ω RCX4391FS002
R1887 RES CARBON FILM 1/4W J 22k Ω or RCX4223FS002
RES CARBON FILM T 1/4W J 22k Ω RCX4223T1001
R1888 RES CARBON FILM T 1/4W J 47k Ω or RCX4473T1001
RES CARBON FILM 1/4W J 47k Ω RCX4473FS002
R1889 RES CARBON FILM 1/4W J 3.3k Ω or RCX4332FS002
RES CARBON FILM T 1/4W J 3.3k Ω RCX4332T1001
R1890 RES CARBON FILM 1/4W J 10k Ω or RCX4103FS002
RES CARBON FILM T 1/4W J 10k Ω RCX4103T1001
R1892 RES CARBON FILM T 1/4W J 4.7k Ω or RCX4472T1001
RES CARBON FILM 1/4W J 4.7k Ω RCX4472FS002
MISCELLANEOUS
B11 HEAT SINK EAJ ASSEMBLY A81H0UH 1EM424644
B12 HEAT SINK EAK ASSEMBLY A81H0UH 1EM424646A
BC1801 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC1851 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC1852 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
L3 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
T1801! PFC CHOKE JCC41-0026 LLEE0Z0XB009
T1831! TRANS INV SRX40ER-E240000H8501 LTZ4PZ0TE003
Ref. No. Description Part No.
FUNCTION CBA
Consists of the following:
----------
RESISTORS
R108 RES CARBON FILM 1/4W J 220 Ω or RCX4221FS002
RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R109 RES CARBON FILM T 1/4W G 47k Ω RCX4473T1002
R111 RES CARBON FILM T 1/4W G 9.1k Ω RCX4912T1002
R113 RES CARBON FILM T 1/4W G 11k Ω RCX4113T1002
R114 RES CARBON FILM T 1/4W G 16k Ω RCX4163T1002
R115 RES CARBON FILM T 1/4W G 27k Ω RCX4273T1002
R116 RES CARBON FILM T 1/4W G 56k Ω RCX4563T1002
SWITCHES
SW101B TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW103B TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW104B TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW105B TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW106B TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
SW107B TACT SWITCH SKQSAB or SST0101AL038
TACT SWITCH TC-1104(H=5.0) or SST0101DNG02
TACT SWITCH KSM0612B SST0101HH003
Ref. No. Description Part No.
IR SENSOR CBA
Consists of the following:
----------
CAPACITORS
C113 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
CAP ELE 47µF/16V/M/85 H7 CEC470KSN003
Ref. No. Description Part No.
C115 CERAMIC CAP.(AX) B K 330pF/50V or CCA1JKT0B331
CAP CERAMIC (AX) 330pF/50V/B/K CA1J331TU061
DIODES
D104 LED GREEN 333GT/E(FNA) or NPWZ33GTEFNA
LED(GREEN) LTL-4234 NPWZ0LTL4234
D105 LED L-53HT or NP4Z000L53HT
LED 333HT/E-L or NPHL00333HTE
LED 333HT/E-K NPHK00333HTE
RESISTORS
R123 RES CARBON FILM 1/4W J 220 Ω or RCX4221FS002
RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R124 RES CARBON FILM 1/4W J 220 Ω or RCX4221FS002
RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R126 RES CARBON FILM 1/4W J 1k Ω or RCX4102FS002
RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
R127 RES CARBON FILM 1/4W J 3.3k Ω or RCX4332FS002
RES CARBON FILM T 1/4W J 3.3k Ω RCX4332T1001
R128 RES CARBON FILM T 1/4W J 100 Ω or RCX4101T1001
RES CARBON FILM 1/4W J 100 Ω RCX4101FS002
MISCELLANEOUS
CL102B WIRE ASSEMBLY 6PIN 6PIN/560MM/AWG26/
UL2
WX1A03P0-022
CL103A WIRE ASSEMBLY 3PIN 3PIN/250MM/AWG28/
UL1
WX1A03P0-205
RS102 SENSOR REMOTE RECEIVER KSM-712TH2E
or
USESJRSKK044
SENSOR REMOTE RECEIVER KSM-712TH5B-
FU or
USEJRS0KK006
SENSOR REMOTE RECEIVER KSM-712TH2M USEJRS0KK001
