Security page
Setting up the security options
If the user selects the 802.1x authentication the PSK or the WEP-Keys don’t have to be defined because the
WI-Client and the Radius-Server will determine these parameters automatically.
Enable authentication with radius
server
Select authentication method:
EAP-PEAP
EAP-TLS
EAP-TTLS
LEAP (CISCO spec.)
Username and Password
Enable WPA and select WPA
mode
WPA = encryption with RC4
WPA2 = encryption conforming to
AES
Select cipher type
PSK = Pre Shared Key
for authentication
with access point
Default WEP key for data
transmission
Authentication type for registration
with an access point
WEP key length
64 bit or 128 bit
Enter keys as hex digits
10 digits for 64 bit WEP
26 digits for 128 bit WEP
There must be defined at least one
key that is defined as „default
WEP key“
Illustration 8: Security page
WI-Client Manual Version 2.16 V3 11
