Technical features:
Processor Type 32bit network processor 250MHz clock
Memory 256KByte program (internal)
64KByte data (internal)
4MByte flash (external)
4MByte SDRAM (external, optional)
Interface Ethernet 10/100 Mbps fast ethernet auto MDI/MDIX
Serial 1 RS232 with control lines
RTS, CTS, DSR, DTR,DCD (input), RI (input)
(optional as RS485, RS422)
Serial 2 Same as serial 1 but only RS232
Mini-PCI Socket for RF cards with Atheros chipsets
(AR5112, AR5113)
Relay (optional) Relay contact
can be operated over LAN or WLAN
Connection with circular M8-4pin connector
AUX input (optional) Isolated input with optocouple
LEDs LEDs - Power (green)
- WLAN (green, red)
- LAN (green, red)
- SER1 (green, red)
- SER2 (green, red)
Power supply Connector Circular M8-3pin connector with screw locking
Power consumption < 2.5W (typ.) < 3W (max.)
Voltage range Standard: 8-30V non isolated
Temperature
range
operating 0 - 70°C ( 32 - 158°F)
storage -20 - 80°C ( -4 - 176°F)
Dimensions Board 120x100x20mm
Case standard: 125x105x40mm
Weight approx. 500g
WLAN - Interface:
WLAN Encryption 64, 128bit WEP, AES
Security 802.11i WPA + WPA2 (Wifi Protected Access) (PSK/TKIP)
802.1x (EAP-TLS, EAP-PEAP), LEAP
Data rates 802.11b 11, 5,5, 2 & 1 MBit/Sec.
802.11g 54, 48, 36, 24, 18, 12, 9, 6 MBit/Sec.
802.11a 54, 48, 36, 24, 18, 12, 9, 6 MBit/Sec.
Frequencies ISM band: 2.400 MHz to 2.483 MHz
U-NII band: 5.150 MHz to 5.350 MHz (ETSI, RegTP indoor)
5.470 MHz to 5.725 MHz (ETSI, RegTP outdoor)
Channels 802.11b/g:
ETSI: 1-13, (3 non overlapping)
802.11a:
ETSI: 12 non overlapping (5.150-5.350 & 5.470-5.725 MHz)
Power output 802.11b/g: 18dBm peak
802.11a: 18 or 17dBm
WI-Client Manual Version 2.16 V3 5
