Funkwerk focX 2 - Technical specifications overview

User Manual Product description
Handheld focX®2
1405.150.10001.BH.EN.8 | 1.0.0 13 | 32
3.5 Technical data in overview
Environmental characteristics
Operating temperature
-25 °C to + +55 °C
Storage temperature
-40 °C to +70 °C
Protection class
IP65
Waterproof
Permanently waterproof up to 1.00 m
Depth
Dust-tight
Dust-impermeable
Shock resistant
Shock-protected
Dust-impermeable
Relative humidity
annual average 75%, 30 days a year permanently 95%
Chemical resistance
against influence from brake fluid, engine and gearbox oil
Dimensions
Height
147.5 mm
Width
72.2 mm
Depth
35 mm
Weight
approx. 342 g
Technical Data
Display
3.5" colour display, 320 x 480 pixels (HVGA)
Display resolution
HVGA 320*480, min 165 PPI
TFT viewing angle stability
120°
brightness
min. 320 cd/m²
Audio
1 microphones, 2 loudspeakers
Battery
5.500 mAh lithium-ion battery (replaceable)
Radio features
Frequency bands
2G/GSM/GSM-R
ER-GSM/GSM 900/E-GSM 900/DCS 1800
3G/WCDM
2
B1/B2/B5/B8
4G/LTE
2
B1/B3/B5/B7/B8/B20/B28/B34/B38/B39/B40/B41/B42
Transmission power
2 W (GSM/GSM-R), 1 W (DCS 1800),
250 mW (3G/WCDM), 200 mW (4G/LTE)
WLAN
IEEE 811 Standards a/b/g/n/ac
Bluetooth
BLUETOOTH 5 BLE
Interfaces
 USB-C (data interface, headset, external operating device/microphone, external plug-in
power supply)
 GNSS (GPS, Galileo, Glonass, Beidou)
 NFC
2
available in future software versions
