10
TV Overview
Front Panel
IR Receiver
A soft light illuminates when the
television power is on.
2. INPUT - After connecting your DVD, cable box, etc. select the appropriate input source to view. Press the
button to display the input options. Press the buttons to highlight the input source and
press the button to select.
3. MENU - Press the button to display. Press to select from the 6 menu options available.
Press the buttons to select a feature from the selected menu then press the buttons
to adjust the volume settings.
4. Channel (-CH+) - Press the buttons to select a channel in the TV mode.
5. Volume (-VOL+) - Press the buttons to adjust the volume up or down.
1. POWER - Press the
button to turn the TV ON/ OFF (standby). The screen image will
appear within a few seconds, and the LED will turn on.
To Next Page
