Protection
PV Over Current
The Solar Charge Controller will limit input power to 300W or 600W depending on model. A PV
array with higher maximum power than the MPPT's rated power will be limited to the rated
power of the device.
PV Short Circuit
When PV short circuit occurs, the controller will stop charging.
PV Reverse Polarity
The MPPT is protected against connecting PV leads in the reverse order.
Battery Reverse Polarity
The MPPT is protected against connecting battery leads in the reverse order.
Battery Over voltage
When battery voltage reaches the voltage set point of over charging voltage, the controller will
stop charging the battery to protect the battery.
Controller Overheating
The MPPT controller will cut off its output when the internal temperature reaches a high level.
The controller will resume operation when the internal temperature has decreased to an
appropriate level.
