Furuno 1823C Installation Manual

i
v
Optional supply
Name Type Code No. Qty Remarks
000-013-484 For GD-1900C, 100 VAC
000-013-485 For GD-1900C, 110 VAC
000-013-486 For GD-1900C, 220 VAC
PR-62
000-013-487
1
For GD-1900C, 230 VAC
Rectifier
RU-3423 000-030-443 1 For MODEL series
External buzzer OP03-136 000-086-443 1
MJ-A6SPF0014-010 000-144-421 1 For NavNet, 1 m
MJ-A6SPF0014-050 000-144-422 1 For NavNet, 5 m
MJ-A6SPF0014-100 000-144-423 1 For NavNet, 10 m
MJ-A6SPF0014-200 000-144-424 1 For NavNet, 20 m
MJ-A6SPF0014-300 000-144-425 1 For NavNet, 30 m
MJ-A6SPF0012-050 000-134-424 1 For navaid, 5 m
MJ-A6SPF0012-100 000-133-817 1 For navaid, 10 m
MJ-A6SPF0003-050 000-117-603 1 w/6P connector, 5 m
MJ-A6SPF0009-100 000-125-236 1 w/6P connector, 10 m
MJ-A6SPF0007-100 000-125-237 1 For compass, 10 m
MJ-A7SPF0007-050 000-144-418 1
For external buzzer, PC,
w/7P connector, 5 m
MJ-A6SRMD/TM11AP8-005 000-144-463 1 Adapter cable for HUB
MJ-B24LPF0008-100 000-145-125 1 For remote display, 10 m
MJ-B24LPF0008-200 000-145-126 1 For remote display, 20 m
Cable assy.
MJ-B24LPF0008-300 000-145-127 1 For remote display, 30 m
RGB output
cable kit
OP03-176 008-526-360 1 For external monitor
ARP kit ARP-11 008-523-050 1 ARP Board, for radar only
NTSC/PAL
interface kit
OP03-175 008-523-070 1 Connection video source
Mounting
bracket (1)
OP03-92 008-445-070 1 For MODEL1833C
Mounting
bracket (2)
OP03-93 008-445-080 1 For MODEL1823C
Chart card - - - Specified when ordering.
RAM card 00RAM02MC-004 004-371-790 1 2 MB
Remote
controller set
RMC-100 000-089-885 1
Modification kit
for C-map
MODEL17*2/C-MAP 008-525-200 1
See modification instruction
E42-00005-x
EMI core E04R241336A 000-146-335 1 For remote display cable connection
Memory card
interface unit
CU-200-NAV 000-081-567 1
w/two chart card slots
