1-20
1.4 Mounting of Power Supply Unit for MODEL
1953C
MODEL 1953C has its own power supply because of high power consumption.
The power supply unit can be installed almost anywhere provided the location is dry,
well-ventilated, sufficient maintenance space is provided (within 5 m from the display unit).
Note: Do not install the power supply unit on the overhead.
Service space: 150
Service
space: 100
Service
space: 100
Power supply unit
To Next Page
