Furuno 1823C Installation Manual

1-19
Antenna unit chassis, cover opened
10. Fix the signal cable with the cable clamp.
11. Release the stay and close the cover. Loosely fasten the cover fixing screws; you will
have to make some adjustments inside after completion of wiring.
Note: When closing the cover, set the gaskets to grooves in the bottom chassis, then
tighten bolts.
BOTTOM
CHASSIS
GASKET
GROOVE
SCANNER BOLT
Torque : 9.8 ±0.1 N m
.
