6.MAINTENANCE & TROUBLESHOOTING
6-3
PROCESSOR UNIT TEST
ROM: OK 6454002-**.**
RAM: OK EEPROM: OK
RUDDER ANGLE OK 1
BYPASS/CLUTCH OK
REMOTECONT1 ON
REMOTECONT2 NOT USED
INPUT VOLTAGE 24.8 V
HEADING SENSOR: - -
PORT1/PORT2/RS232 - -/- -/- -
PROCESSOR UNIT ID:2097151
**.**: Program version no.
CONTROL UNIT TEST
ROM: OK 6454003-**.**
RAM: OK EEPROM: OK
COMMUNICATION: OK
CONTROLLER ID: 255
CAN ID: XXXXXXX
PUSH MENU KEY TO RETURN.
CONTROL UNIT
**.**: Program version no.
For Navpilot-520,
"6454004-**.**" appears.
HEADING SENSOR TEST
This test should be done while turning the connected sensor (PG-500) in a circle
at a rate of 60°/min. or more. If the sensor does not rotate, this test terminates
after one minute with NG result.
ROM: OK 6454101-**.**
RAM: OK EEPROM: OK
SENSOR: OK
RATE SENSOR: OK
TURN MORE THAN 180 IN 60
SECONDS.
PUSH MENU KEY TO RETURN.
HEADING SENSOR
**.**: Program vrsion no.
