6.MAINTENANCE & TROUBLESHOOTING
6-5
RUDDER SETUP AND AUTO TEST
The rudder test checks the following, and then shows the result of the check.
• Drive type
• The presence or absence of bypass/clutch circuit
• Rudder deadband
• Rudder speed
• Duty
This test should be executed when the boat does not run because of moving the
rudder.
When the rudder test is finished, a beep sounds and the message “RUDDER
TEST COMPLETED” and the results are shown.
RUDDER SETUP AND AUTO TEST
DRIVE TYPE: _ _ V
BYPASS/CLUTCH: _
DB : _ _. _ SPD: _ _._ /S
RUDDER DUTY: 50%
40 20 10 5
5 10 20 40
_ _
Rudder test
DRIVE TYPE: REVERSIBLE or SOLENOID
BYPASS/CLUTCH: EXIST or NON
DB: Shows the rudder deadband
SPD: Rudder speed
RUDDER DUTY: Rate of the rudder movement
