3.3 Bridge Control panel
Two panels at main navigation workstation
Enable Light will lit, whenever
the watch safety system is
activated from captain’s cabin
If the pushbutton is pressed, the
audible sound and all lamps are
illuminated in the panel for test
purposes.
Buzzer will sound intermitted
sound in case the operator
has not made any action
within timer set-value.
If there is no operator activity
within following 30 seconds,
alarm is released in captain’s
cabin, public areas and
back-up navigator’s cabin
In case the operator fails to
respond to any bridge alarm
within 60 seconds, alarm is
transferred to captain’s
cabin, public areas and
back-up navigator’s cabin.
Dimmer potentiometer
will adjust the back light
value of pushbutton
lamps. The warning
lamp light level is not
adjustable.
Note The timer set-value
means the watch time
period set on Timer
Control Unit, located in
captain’s cabin
Call Back-up
pushbutton activates
the buzzer in the back
up navigator’s cabin,
captain’s cabin and
public areas.
Warning light will flash in case
the operator has not made any
action within timer set-value,
minus 30 seconds
Whenever the push-button is
pressed, the full timer value is
restored in the watch safety
system
