Furuno DFF1 - Optional Temperature Sensors; Transom Mount Temperature Sensor T-02 MTB

11
1.7 Optional Temperature Sensors
1.7.1 Transom mount temperature sensor T-02MTB
• Fix the cable at a convenient location with cable clamp.
• When the cable is led in through the transom board, make a hole of approx. 17 mm
in diameter to pass the connector. After passing the cable, fill the hole with a seal-
ing compound.
Temperature sensor T-02MTB
M5x20
Mount sensor
flush with hull bottom.
D
D>50cm
