Furuno FCV-668 - Specifications

SP - 1
SPECIFICATIONS OF COLOR VIDEO SOUNDER
FCV-668
1. GENERAL
(1) Display 6-inch diagonal CRT
(2) Echo Color 8 colors (including background color) according to echo intensity.
Monochrome display is also available. The background color is selectable
from blue, light blue, white and black.
(3) Basic Range Meters: 5/10/20/40/80/150/200/300
Feet: 15/30/60/120/200/400/600/1000
Fathoms: 3/5/10/20/40/80/100/150
Passi/Braza: 3/5/10/30/50/100/150/200
The basic ranges can be changed on the system menu.
(4) Range Shift Up to 300 meters (1000 feet, 150 fathoms, 200 passi/braza)
(5) Zoom Range Times 2, 3, 4 and 5 ranges
(6) Bottom Lock Expansion Range
5/10 meters, 10/20 feet, 2/5 fathoms, 2/5 passi/braza
(7) Auto Mode Automatic adjustment of range and gain
(8) Display Mode Normal, Normal and Marker Zoom, Normal and Bottom-lock Expansion
Normal and Bottom Zoom, Graphical and Numerical displays,
Data Display and A-scope Display
(9) Zoom Display Marker Zoom, Bottom Zoom and Bottom-lock Expansion
(10) Display Advance Speed Lines/TX: Freeze, 1/8, 1/4, 1/2, 1/1, 2/1
(11) TX Frequency/ Output power
50 and 200 kHz (selected), 300 W
(12) Pulse-length/TX rate
Display End Depth (m) 5 10 20 40 80 150 300
Pulse-Length (ms) 0.2 0.2 0.2 0.4 0.8 1.5 3.0
TX Rate (pulse/min) 600 600 600 375 187 100 50
(13) Interference Rejecter Rejects unwanted signals by comparing last and present echoes in
strength.
(14) Alarm Fish and Bottom alarms, Temperature alarm
(15) Input/output data NMEA 0183 or CIF format
NMEA Input RMB, BWC, RMC, RMA, GLL, VTG, VHW, MTW, XTE
NMEA Output SDDBT, YCMTW*, VWVHW*, SDDPT
CIF Input L/L, Ship’s speed, Course, Waypoint ID, Range/bearing to Waypoint,
Water temperature, Cross-track Error
CIF Output Depth, Water temperature*, Ship’s Speed*
