Furuno FE-700 Software Guide

8
2.5 Saving a file
The time selection data specified at previous section can be saved with any name in Excel
format. Select File - Save as from the menu bar or click the FileSave button . The normal
Windows Save as dialog box appears. Type file name, select the location to save and click
the OK button.
2.6 Printing a file
You can print out the time selection data specified at previous section. Select File - Print
from the menu bar(or Ctrl +P) or click Print button The normal Windows Print dialog
box appears. Click the OK button to print out the data.
2.7 Exiting the program
Select File - Exit from the menu bar. The program closes and return to the Windows
screen.
2.8 Error Messages
Below is a list of error messages shown on the screen.
Message Meaning Remedy
Initializing error!: COM Failed initialization of
COM port. For example,
other application uses
COM port.
Match the “serial port”
setting (section 1.3) with
the COM port connection
of the PC.
Communication error! Failed communication
with FE-700.
Confirm the connection
between FE-700 and
COM port of PC.
Can not open! Could not read or save
data.
No data
Not enough memory to
save!
There was not enough
space on the hard disk on
the PC.
Delete unnecessary files.
Invalid data! Specified time was wrong. Try to specify date/time
again. (less than 12
hours).
Not found the data! There was no data in the
file at specified time.
Try to specify date/time
again.
PUB. No. OME-23661
FE-700 DATA REC.SOFT
(
YOSH
)
FIRST EDITION : JUL. 2000
E : APR. 1, 2004

Furuno FE-700 Specifications

General

Frequency	50/200 kHz
Power Supply	12-24 VDC
Operating Temperature	-15°C to +55°C
Display Type	Color LCD
Interface	NMEA 0183
