Furuno FELCOM 16 Installation Manual

iii
SYSTEM CONFIGURATION
Antenna Unit Exposed to Weather
Communication Unit Protected from Weather
Other Units Protected from Weather
PERSONAL
COMPUTER
(PC/AT compatible)
ANTENNA
UNIT
IC-116
COMMUNICATION UNIT IC-216
(with internal GPS receiver)
POWER SUPPLY
100-115/200-230
1φ, 50/60 Hz
: Standard
: Option
: Local Supply
POWER SUPPLY
12-24 VDC
AC-DC
Power Supply
PR-240
POWER
I
O
INMARSAT MINI-C MOBILE EARTH STATION FURUNO
POWER
LOGIN
TX
ERROR
PRINTER
JUNCTION BOX
IC-315
SSAS ALERT UNIT*
IC-307
SSAS ALERT UNIT*
IC-307
*: At least two SSAS Alert Units are required.
CATEGORY OF UNITS
(Max. 3 units)
