Furuno FM-2721 - System Configuration

viii
System Configuration
POWER
DISTRESS
CH70
RX ANT
12VDC
IEC61162-1(NMEA)
REMOTE 2REMOTE 1
ANT
SPKR
+ -
NAV device
REMOTE HANDSET BREMOTE HANDSET A
(OPTION)
(OPTION)(OPTION)
(OPTION)
(OPTION)
SPEAKER
GGA,RMC,GLL,ZDA
(HS-2721) (RB-2721A) (HS-2721) (RB-2721B)
(IEC61162-1)
5m MAX 50m
GROUND
12V DC
VHF & CH70 RX ANT CH70 RX ANT
(5D-2V) (5D-2V)
(150M-W2VN) (150M-W2VN)
(SEM-21Q)
TRANSCEIVER
UNIT
FM-2721
