3. PLOTTER OPERATION
3-15
Icon data
You may place the cursor on any icon to find information about the selected icon.
1. For example, place the cursor on a lighthouse icon.
Place the cursor on a lighthouse icon.
34° 22. 3456'N 359.9°
M
TRIP
NU
080° 22. 3456'E
19.9 kt 99.9 nm
GO TO
CURSOR
CENTER
+
MARK
ENTRY
16.0nm
D. BOX
ON /OFF
MODE
NTH UP
+
Lighthouse icon
2. Push the ENTER knob to show data. For example, the following window appears for a
lighthouse.
Objects
Lighthouse
Towe r
Light
Underwater Rock
Depth contour
Depth contour
Depth area
Source of data
Object windows
3. Use the Trackball to select the item desired.
4. Push the ENTER knob to display detailed information.
To Next Page
