3. PLOTTER OPERATION
3-17
Objects
Port area
Port/Marine
Fuel station
Water
Electricity
Showers
Public toilets
Public telephone
C-map, port service displa
5. Press the DATE soft key to open the DATE window.
CHANGE DATE
(DAY. MONTH. YEAR)
2 8. 10. 1998
LIMIT: 31.12.2099
Date window
6. Use the Trackball to position the cursor where desired, then enter date with the
alphanumeric keys. Repeat to enter complete date.
7. Push the ENTER knob to show the tidal graph for entered date.
8. Use the Trackball to locate the vertical cursor on the hour desired.
9. Use the Trackball to shift the horizontal cursor to select draught.
10. See the time, height and draught indications in left of the tide graph for tide information.
11. Press the CANCEL soft key twice to close the TIDE window.
Port service icons
Selected C-MAP shows services available at ports, with
lists.
1. Use the Trackball to place the cursor on the sailboat
icon (denotes a port or harbor) desired.
2. Push the ENTER knob.
3. Select the service name desired. The services available
appear.
4. Press the CANCEL soft key.
Note: When “Port/Marine” is selected, you can show a
picture of the port selected, provided such data is available
on the chart card.
FIND function
When the Objects window is shown, objects can be listed according to their categories.
1. Press the FIND soft key with the Object window.
2. Operate the Track ball to choose the category to list, and then press the ENTER soft
key or ENTER knob.
A list appears.
3. Press the CANCEL key twice to finish.
