4. INSTALLATION
4-12
Pattern 2: Dimmer controller is commonly used. A total of 10 RD-50s can be connect-
ed in a daisy chain. A maximum of nine sub RD-50s can be connected.
Connection of each unit
Process each cable referring to the illustrations below and on the next page.
Fabrication of RD-50 power cable DPYC-1.5 (indoor type)
Fabrication of sensor signal cable TTYCS-1 (indoor type) / TTYCS-4
Remote display RD-50 (main)
FURUNO
DAY
NT
DIMMER CONTROLLER
RD-502
BRILL
RD-502
RD-501
Remote display RD-50 (sub)
21 21345
6
2 134
TB1
TB4
TB2
TB3
DC
Sensor
Sensor
21 21345
6
2
1
3
4
TB1
TB4
TB2
TB3
DC
FURUNO
DISP UNIT MODE
REMOTE CONTROLLER
RD-501
Remote display RD-50 (sub)
21 21345
6
2 134
TB1
TB4
TB2
TB3
DC
Sensor
Sensor
Sensor
Sensor
70
6
Vinyl tape
Armor
40
Fix armor by cable clamp.
M4
100 (for TB2 & TB4)
80 (for TB3)
35
7
Armor
Vinyl tape
Shield
Fold back and wrap internal shield and
fix it by cable clamp.
