Furuno TZT9 User Manual

10. CAMERA/VIDEO/FUSION-Link
10-9
Example2: VHF in the full screen
Note: For details, see the manual for the FUSION-Link equipment.
Method 2
: RotoKey menu (for minimized window)
Select [Fusion Ctrl] from the RotoKey menu to display the audio control bar on each
display. The following is the example on the chart plotter.
Drag the
circle icon
to adjust
squelch.
Tap: Switch channel selection mode between
preset and manual.
Long tap: After selecting channel in manual mode,
long tap to register the channel as preset channel.
Mute or unmute.
Turn down volume.
Turn up volume.
Select channel.
Tap to
select
CH16.
Channel
selection
mode
Scan
Ch.
Menu
Close
Tap to
go to
FUSION
screen
(full
window).
Tap to
turn off
the bar.
For iPod
For VHF
Ch.
