Specifications
Signal to Noise >95dB
Separation >60dB
Input Sensitivity 300mV - 8V
LP Variable Crossover 40Hz - 160Hz @ 18dB/octave
HP Variable Crossover 40Hz - 600Hz @ 12dB/octave
Variable Bass Boost 0 - + 18dB @ 45Hz
Variable Subsonic Filter 20Hz - 55Hz @ 18dB/octave
Input Impedance 20k Ω
Damping factor >200
T.H.D 0.05%
Fuse Ratings 1 x 25A
Dimensions(mm) 229 (W) x 296(L) x 53vz(H)
12.6 Volt power output specification
50 Watts RMS x 2 @ 4Ω 1% THD+N
96 Watts RMS x 2 @ 2Ω 1% THD+N
160 Watts RMS x 1 @ 4Ω Bridged 1% THD+N
14.4 Volt power output specification
65 Watts RMS x 2 @ 4Ω 1% THD+N
100 Watts RMS x 2 @ 2Ω 1% THD+N
200 Watts RMS x 1 @ 4Ω Bridged 1% THD+N
010
INSTALLATION
Trouble Shooting
Problem Cause Solution
Power LED
not ‘ON
Fuse at battery blown
or not installed
Replace with correct type and rated fuse.
Improper connections
Check that the ground wire, power wire and the remote
wires are connected to the correct terminal
Status LED
‘ON’
Fuse blown
Replace with correct type and rated fuse.
Amplifier too hot
Move the amplifier into a more ventilated area
Speaker wires shorted
Check that there are no speaker wires shorted to any
other wire and also check if any wire is shorted to
ground
Internal malfunction
Disconnect all wires except ground, power and remote. Then turn the
amplifier ’ON’, if the protection light is still ’ON’ then return for service
