Receiver
●S.BUSServo
Since the channel number is memorized by
the S.BUS itself, any connector can be used.
When the SBD-1 or SBD-2 (sold separately)
is used, ordinary servos can be used with the
S.BUS system.
●Whenseparatepowersupplyused
When a large number of servos are used or
when high current servos are used, the servos
can be driven by a separate power supply by
using a separate Power Supply 3-way Hub.
●
7HUPLQDOER[
Four connectors can be inserted
●
7HUPLQDOER[7%33
6 connectors can be inserted
Three connectors can be
inserted.
Used when using a separate
power supply battery.
Orange
Green
*When using 8/SB as S.BUS, you must set the receiver to
Mode B,D,E. See R3008SB CH MODE TABLE.
6%
Warning
Power supply
Please make sure that you
use a battery that can deliver
enough capacity for the
number and kind of servos
used. Alkaline batteries
cannot be used.
